SWRGM-49N Module SWRGM-49N Harness SWC Cables
Harness
Antenna Adapter
Crux Interfacing Solutions • Chatsworth, CA 91311
phone: (818) 609-9299 • fax: (818) 996-8188 • www.cruxinterfacing.com
rev.0720221 of 2
R O P LA TADI RE CEM EN
SW E T IONC R ENT
+
R
INTERFACING SOLUTIONS
- Retains factory Steering Wheel Controls.
- Retains RAP (Retained Accessory Power).
- Includes antenna adapter.
PRODUCT FEATURES:
PARTS INCLUDED:
INSTALLATION DIAGRAM:
AFTERMARKET
RADIO
Reverse Gear Purple/White
Illumina on (+) Orange
+12V Constant Yellow
+12V ACC Red
Ground Black
Right Front (+) G yra
Right Front (-) Gray/Black
Le Front (+) White
Le Front (-) White/Black
Le Rear (+) Green
Le Rear (-) Green/Black
Right Rear (+) Violet
Right Rear (-) Violet/Black
TO FACTORY
HARNESS
3.5MM SWC CABLE
Plug in the 3.5MM SWC cable to the 4-pin port
on the module. See “DIP SWITCH SETTINGS” section.
1 2 3
ON
AFTERMARKET
RADIO SELECTOR
(See Chart)
Chime volume
adjustment
44-PIN
CONNECTOR
To aftermarket
Radio SWC Input
16-Pin Black
Connector
Non Bose Bose
See page 2 for Audio
connection options
To Aftermarket
Radio Rear Camera Input
To OEM Camera
Harness
Gray 16-Pin
Connector
Vehicle Speed Sense
(Green/White)
Option A:
Option B:
BLUE / YELLOW
(for Kenwood or JVC)
Insulate with tape
if not being used
OR
SWRGM-49N
Radio Replacement Interface with Steering Wheel Control
Retention for Select GM LAN Bus Vehicles 2010-2017
TROUBLESHOOTING
LED
LIGHT
LED MODULE FEEDBACK
Solid blue
Flashing blue
Solid red Module providing 12V ACC
CAN not recognized
CAN recognized
12V ACC OFFRed off
