CAUTION!
All accessories, switches, climate
controls panels, and especially air bag indicator
lights must be connected before cycling the
ignition. Also, do not remove the factory radio
with the key in the on position, or while the
vehicle is running.
Metra. The World’s Best Kits.
®
MetraOnline.com © COPYRIGHT 2018 METRA ELECTRONICS CORPORATION REV. 5/15/18 INST99-7526B
INSTALLATION INSTRUCTIONS
99-7526B
KIT FEATURES
• ISO DIN radio provision with pocket
• Painted matte black
KIT COMPONENTS
• A) Radio trim panel (a) • B) Radio trim panel (b) • C) Radio housing base• D) Radio brackets • E) Radio support bracket • F) (4) Panel clips
• G) (2) #8 x 1/2” Phillips screws
TOOLS REQUIRED
• Panel removal tool • Phillips screwdriver
• 10mm Socket wrench • 1/8” drill bit
TABLE OF CONTENTS
Dash Disassembly ..................................................2
Kit Preparation .......................................................2
Kit Assembly ..........................................................3
A B C
G
D E
Mazda 3 2014-up*
*Visit MetraOnline.com for up-to-date vehicle specific applications.
F
WIRING & ANTENNA CONNECTIONS
(sold separately)
Wiring Harness: 70-7903L (without amp)
Antenna Adapter: 40-HD10L
Steering wheel control interface: ASWC-1 & AX-
MAZ28SWC-6V (will also retain backup camera)
