PR-LOC2.2 & PR-LOC2.4
I N S TA L L AT I O N I N S T R U C T I O N S
MetraOnline .com © COPYRIGHT 2022 METRA ELECTRONICS CORPORATION REV. 9/12/22 INSTPR-LOC2.2 & PR-LOC2.4
TABLE OF CONTENTS
Quick Start Guide
Things to Know .................................................2
Connections .......................................................2
Gain setup
Basic setup.........................................................3
Advanced Setup ................................................3
Feature Breakdowns ..............................................4
Quick Reference: PR-LOC2.2 ..................................5
Diagram: PR-LOC2.2 ...............................................6
Quick Reference: PR-LOC2.4 ..................................7
Diagram: PR-LOC2.4 ...............................................8
Specifications .........................................................9
Universal Premium LOCs
PR-LOC2.2 2 IN - 2 OUT with Max Input 20v
PR-LOC2.4 2 IN - 4 OUT With Max Input 20v
TOOLS RECOMMENDED
• Digital Multi-meter
• Test Tones
Universal Premium LOCs
The Proscenium PR-LOC2.2 & PR-LOC2.4 can be used to add amplifiers to an audio system that does not have RCA outputs or when replacing
an OEM radio and retaining the factory amplified system. Variable Gain Controls with Clipping Indicators, Selectable Ground Isolation Load and
Select features ensure a pure, noise-free signal for any type of audio system.
PR-LOC2.4
Line Out Converter (LOC)
KIT COMPONENTS
PR-LOC2.2
Line Out Converter (LOC)
