APPLICATIONS
METRA. The World’s best kits.
™
metraonline.com1-800-221-0932
© COPYRIGHT 2015 METRA ELECTRONICS CORPORATION
REV. 4/23/2015 INST99-9700
CAUTION: Metra recommends disconnecting the
negative battery terminal before beginning any
installation. All accessories, switches, and especially
air bag indicator lights must be plugged in before
reconnecting the battery or cycling the ignition.
NOTE: Refer to the instructions included with the
aftermarket radio.
INSTALLATION INSTRUCTIONS FOR PART 99-9700
• ISO DIN radio provision
• Included interface and LCD info screen
• A) Radio housing • B) Radio brackets • C) LCD screen • D) LCD back plate
• E) (10) #8 x 3/8” Phillips screws • Axxess interface (not shown)
KIT FEATURES
KIT COMPONENTS
WIRING & ANTENNA CONNECTIONS (sold separately)
Wiring Harness: • Included interface
Antenna Adapter: • 40-EU10 Handle bar controls: • ASWC-1
• Panel removal tool • Phillips screwdriver
• Torx screwdrivers • Allen wrenches
TOOLS REQUIRED
Harley-Davidson Street Glide, Electra Glide, Ultra and
Limited models 2014-up / Road Glide 2015-up
99-9700
A
B
C
D
E
Fairing Disassembly
– Harley Davidson Street Glide, Electra Glide,
Ultra, and Limited models 2014-up ...................2-3
– Harley Davidson Road Glide 2015-up ................... 4
Kit Assembly .......................................................... 5
Axxess interface installation ..............................6-7
Troubleshooting/Updating 99-9700 ...................... 8
Table of Contents
