Factory Radio Removal Keys
120 86-9001
Parts
Supplied:
▲
(2) Keys
Revision 05/05/03
Horizontal Keys
*120869001*
®
Copyright 2003 Crutchfield Corporation
1. Disconnect negative battery cable to
prevent any electrical short.
2. Identify right and left keys by markings
“R” and “L” (Figure 1).
3. Note applications of each key (Figure 1).
This instruction sheet illustrates
Volkswagen Beetle, Jetta and Passat.
4. Check key slots on face of factory radio.
If slots in radio face are vertical:
Select the vertical keys. Slide keys into
slots until they click into place (Figure 2).
Pull out radio, disconnect wiring harness
and antenna to remove.
If slots in radio face are horizontal:
Select horizontal keys (the most pointed).
Slide keys into slot until they click into
place (Figure 3). Pull out radio,
disconnect wiring harness and antenna
to remove.
Note: Some tall factory units will have
four slots and will require two sets of keys
(Figure 4).
FIGURE 1
FIGURE 2
FIGURE 3
FIGURE 4
Vertical Keys
R
L
Mercedes
Applications
Vertical Keys
Vertical Slots
Horizontal Keys
Horizontal Slots
Before starting, compare items on your invoice with items
received. If any parts are missing, first carefully check through
p
ackaging material. If an item is missing, please call:
Crutchfield at 1-888-955-6000
