REV. 1/26/2017 INST99-3307G
INSTALLATION INSTRUCTIONS FOR PART 99-3307G
METRA. The World’s best kits.
®
metraonline.com
© COPYRIGHT 2017 METRA ELECTRONICS CORPORATION
CAUTION!
All accessories, switches, climate controls panels,
and especially air bag indicator lights must be connected before
cycling the ignition. Also, do not remove the factory radio with
the key in the on position, or while the vehicle is running.
• ISO DIN radio provision with pocket
• ISO DDIN radio provision
• Painted gray to match factory finish
• A) Radio trim panel • B) Radio brackets • C) Pocket • D) (6) #8 x 3/8” Phillips screws
• E) (2) #10 x ¾” Phillips screws • F) (2) #10 panel clips • G) Axxess interface and wiring harness (not shown)
KIT FEATURES
KIT COMPONENTS
WIRING & ANTENNA CONNECTIONS (sold separately)
Wiring Harness: • Axxess interface and harness included
Antenna Adapter: • 40-EU55
• Panel removal tool • Phillips screwdriver
• 9/32” socket wrench
TOOLS REQUIRED
Chevy Equinox 2010-2015 / GMC Terrain 2010-2014
(with monochrome display)
99-3307G
A
Table of Contents
B
C
E FD
Dash Disassembly ................................................. 2
Kit Preparation ....................................................... 3
Kit Assembly
– ISO DIN radio provision with pocket ...................... 4
– ISO DDIN radio provision ...................................... 4
Axxess Interface Installation .............................5-7
