Metra. The World’s Best Kits.
®
MetraOnline.com © COPYRIGHT 2019 METRA ELECTRONICS CORPORATION REV. 1/22/19 INST95-9318B
INSTALLATION INSTRUCTIONS
95-9318B
Attention! Let the vehicle sit with the key
out of the ignition for a few minutes before
removing the factory radio. When testing the
aftermarket equipment, ensure that all factory
equipment is connected before cycling the
key to ignition.
KIT COMPONENTS
• A) Radio trim panel • B) Radio brackets • C) Panel clips (2) • D) Radio screws (8) • E) ASWC-1 interface and wiring harness (not shown)
• F) Axxess interface and wiring harness (not shown) • G) Amplifier interface (not shown) • H) Antenna adapter (not shown)
TOOLS REQUIRED
• Cutting tool • Panel removal tool
• Phillips screwdriver • 3mm Allen screwdriver
• T-20 Torx screwdriver
TABLE OF CONTENTS
Dash Disassembly ..................................................2
Kit Preparation .......................................................3
Kit Assembly ..........................................................4
Axxess Interface Installation .................................5
Final Assembly ..................................................... 10
WIRING & ANTENNA CONNECTIONS
Wiring Harness: Included with kit
Antenna Adapter: Included with kit
Steering Wheel Control Interface: Included with kit
A
BMW 3 & 4 Series* (with NBT iDrive, with MOST
®
Amp) 2014-2016
• F30, F31, F32, F33, F34, F36, F80, F82, F83
Visit MetraOnline.com for more detailed information about the product and up-to-date vehicle specific applications
KIT FEATURES
• ISO DDIN radio provision
• Retains the factory climate controls
• Retains the factory ambient ashtray light (if equipped)
• Includes all necessary data interfaces, wiring harnesses, and antenna adapter, for a
complete installation
• Painted black to match the factory dash
B C D
