CAUTION!
All accessories, switches, climate
controls panels, and especially air bag indicator
lights must be connected before cycling the
ignition. Also, do not remove the factory radio
with the key in the on position, or while the
vehicle is running.
Metra. The World’s Best Kits.
®
MetraOnline.com © COPYRIGHT 2018 METRA ELECTRONICS CORPORATION REV. 1/18/18 INST99-7633
INSTALLATION INSTRUCTIONS
99-7633
KIT FEATURES
• ISO DIN radio provision with pocket
• ISO DDIN radio provision
• Painted high gloss black
KIT COMPONENTS
• A) Radio trim panel with climate controls • B) Radio brackets • C) Keypad • D) Pocket • E) (2) Panel clips • F) (4) #8 x 3/8” Phillips screws
• G) Axxess Interface and wiring harness (not shown)
TOOLS REQUIRED
• Panel removal tool • Phillips screwdriver
• Torx screwdriver
TABLE OF CONTENTS
Dash Disassembly ..................................................2
Kit Preparation .......................................................2
Kit Assembly
–ISO DIN radio provision with pocket ..................3
–ISO DDIN radio provision .....................................3
Axxess Interface Installation .............................4-11
WIRING & ANTENNA CONNECTIONS
Wiring harness: • Axxess interface and harness included
Antenna adapter: • 40-NI12 (sold separately)
Steering wheel control interface: • ASWC-1 (sold separately)
A B DC FE
Nissan Maxima (with Technology Package)
2009-2014
Nissan Maxima (with NAV)
2009
