Instruction Manual

DE: Bedienungsanleitung - de.startech.com

FR: Guide de l'utilisateur - fr.startech.com

ES: Guía del usuario - es.startech.com

IT: Guida per l'uso - it.startech.com

NL: Gebruiksaanwijzing - nl.startech.com

PT: Guia do usuário - pt.startech.com

Manual Revision: 03/27/2012

For the most up-to-date information, please visit: www.startech.com

Packaging Contents

• 1xVS122HDMIUswitch

• 1xHDMIcable

System Requirements

• HDMIenableddisplaydevice(i.e.HDTV,monitor,projector,etc.)

• HDMIenabledvideosources(i.e.computer,gameconsole,etc.)

VS122HDMIU

2 Port Auto High Speed HDMI Switch

*actual product may vary from photos

Installation

1. ConnectanHDMIcable(notincluded)fromeachofthevideo

sourcedevices(i.e.computer,gameconsole,DVR,etc.)tothe‘IN’

connectorsonthevideoswitch.Port1istheprimaryinputsowill

bedisplayedbydefault.

2. ConnectanHDMIcablefromthedisplaydevice(i.e.HDTV,

monitor,etc.)tothe‘OUT’connectoronthevideoswitch.

3. Turnonthedisplaydevice,followedbythevideosources.

IfthevideosignalonPort1isterminated(i.e.turnedo,cable

disconnected,etc.),thenthevideoswitchwillautomaticallyselect

Port2.OncethevideosignalisrestoredonPort1,thevideoswitch

willautomaticallyswitchbacktoPort1.

Thevideoswitchcanbemanuallytoggledbetweenportsby

pressingthe“Select”buttononthetopoftheunit.Thissettingwill

remainuntilthevideosignalonPort1changes,settingitbackto

automaticmode.

HDMIVideoSources

DisplayDevice

Specications

Video Signal HDMI(1.3)

Number of Ports 2

Connectors 3xHDMItypeAfemale

LEDs

1xPower

2xPortSelectionIndicator

Video Bandwidth 2.5Gbps

Maximum Video Resolution 1080p

Maximum Cable Distance 10m

Audio Support Yes

HDCP Compliant Yes(HDCP1.1)

Power Adapter Self-powered

Operating Temperature 0°C~70°C(32°F~158°F)

Storage Temperature -65°C~150°C(-85°F~302°F)

Humidity 10%~85%RH

Dimensions 63.0mmx59.0mmx15.0mm

Weight 35g

Problemløsning StarTech.com VS122HDMIU

Hvis du har læst manualen omhyggeligt, men ikke fundet en løsning på dit problem, bed andre brugere om hjælp

Specifikationer

Vægt:	35 g
Pakkedybde:	165 mm
Pakkebredde:	20 mm
Pakkehøjde:	130 mm
Antal HDMI-porte:	3
HDCP:	Ja
Dimensioner (BxDxH):	59 x 63 x 15 mm
Materiale:	Plast
Video porttype:	HDMI
