StarTech.com CFASTRWU3 Brugsanvisning
Her er StarTech.com CFASTRWU3 (Hukommelseskortlæser) brugervejledning. 2 sider på sprog med en vægt på 369,604.0 Mb. Hvis du ikke kan finde svar på dit problem Spørg vores community.
Side 1/2
Quick-start guide
FR: Guide de l’utilisateur - fr.startech.com
DE: Bedienungsanleitung - de.startech.com
ES: Guía del usuario - es.startech.com
NL: Gebruiksaanwijzing - nl.startech.com
PT: Guia do usuário - pt.startech.com
IT: Guida per l’uso - it.startech.com
Manual Revision: 01/20/2017
For the latest information, technical specications, and support for
this product, please visit www.StarTech.com/CFASTRWU3.
Package contents
• 1 x USB 3.0 card reader/writer
• 1 x quick-start guide
CFASTRWU3
USB 3.0 Card Reader / Writer for CFast 2.0 Cards
*actual product may vary from photos
Introduction
The CFASTRWU3 USB 3.0 Card Reader/Writer enables you to quickly
access and back up photos and videos from your CFast™ memory
cards to your tablet, laptop, or desktop computer.
Product diagram
About USB 3.0 and USB 3.1 Gen 1
USB 3.0 is also known as USB 3.1 Gen 1. This connectivity standard
oers speeds up to 5Gbps. Any mention of USB 3.0 in this manual
or on the StarTech.com website for CFASTRWU3 refers to the 5Gbps
USB 3.1 Gen 1 standard.
Note: Data transfer rates are dependent upon the speed of the
memory card that you are using and the speed capabilities of the
USB port on your host device.
Connect the card reader/writer
1. Connect the USB 3.0 plug on the card reader/writer to a USB port
on your tablet, laptop, or desktop computer.
2. Insert a CFast memory card into the CFast port on the card
reader/writer.
3. To access content on the CFast memory card, follow the
instructions specic to the OS that you’re running.
When you connect the card reader/writer to your tablet, laptop, or
desktop computer, your system automatically detects and installs
the required software.
Note: The CFASTRWU3 doesn’t require an external power supply, as
it receives enough power through the USB bus that it’s connected to.
USB 3.0 plug
CFast port
Activity LED
Requirements
• A tablet, laptop, or desktop computer with a USB Type-A port
• A CFast memory card
Note: To obtain the maximum USB throughput, you must use a
system with a USB 3.0 port.
The CFASTRWU3 is OS independent and doesn’t require any
additional drivers or software.
Requirements are subject to change. For the latest requirements,
please visit www.StarTech.com/CFASTRWU3.
Disconnect the card reader/writer
Windows
1. On your desktop, click the Safely Remove Hardware icon.
2. In the list that appears, click the card reader/writer.
3. When a message appears saying that it’s safe to do so, remove the
card reader/writer from your laptop, or computer.
Caution! If you remove the card reader/writer before it’s safe to do
so, you could experience lost or corrupted data on your memory
card.
macOS
1. Close any open windows that list the contents of the card
reader/writer.
2. On your desktop, click and drag the USB storage icon to the trash
can icon.
3. Wait ten seconds and then remove the card reader/writer.
Caution! If you remove the card reader/writer before it is safe to do
so, you could experience lost or corrupted data on your memory
card.
Problemløsning StarTech.com CFASTRWU3
Hvis du har læst manualen omhyggeligt, men ikke fundet en løsning på dit problem, bed andre brugere om hjælp
Specifikationer
| Bredde: | 58 mm |
| Dybde: | 246 mm |
| Højde: | 15 mm |
| Vægt: | 37.3 g |
| Antal pr. pakke: | 1 stk |
| Produktfarve: | Sort, sølv |
| Pakkevægt: | 55 g |
| Pakkedybde: | 220 mm |
| Pakkebredde: | 198 mm |
| Pakkehøjde: | 30 mm |
| Kompatible hukommelseskort: | CFast, CFast 2.0 |
| Opbevaringstemperatur (T-T): | -10 - 55 °C |
| Relativ luftfugtighed ved drift (H-H): | 40 - 50 % |
| Driftstemperatur (T-T): | 0 - 70 °C |
| Husmateriale: | Aluminium |
| Hurtig start guide: | Ja |
| Certificering: | CE, FCC, RoHS, REACH |
| LED-indikatorer: | Activity, Power |
| Strømkilde type: | USB |
| Harmoniseret systemkode (HS): | 84719000 |
| Hovedkassen højde (udvendigt): | 270 mm |
| Hovedkassens længde (udvendigt): | 455 mm |
| Hovedkassens bredde (udvendigt): | 355 mm |
| Intern: | Ingen |
| Plug and play: | Ja |
| Produkter pr. hovedkasse (udvendigt): | 160 stk |
| Dataoverførselshastighed: | 5000 Mbit/s |
| Integreret USB-kabel: | Ja |
| Hot-swap: | Ja |
| Understøtter UASP: | Ja |
| Chipsæt: | ASMedia - ASM1153E |
