StarTech.com SDMSDRWU3AC Brugsanvisning
Her er StarTech.com SDMSDRWU3AC (Hukommelseskortlæser) brugervejledning. 2 sider på sprog med en vægt på 333,716.0 Mb. Hvis du ikke kan finde svar på dit problem Spørg vores community.
Side 1/2
Quick-start guide
FR: Guide de l’utilisateur - fr.startech.com
DE: Bedienungsanleitung - de.startech.com
ES: Guía del usuario - es.startech.com
NL: Gebruiksaanwijzing - nl.startech.com
PT: Guia do usuário - pt.startech.com
IT: Guida per l’uso - it.startech.com
Manual Revision: 02/16/2017
For the latest information, technical specications, and support for
this product, please visit www.StarTech.com/SDMSDRWU3AC.
Package contents
• 1 x card reader/writer
• 2 x end caps
• 1 x quick-start guide
Requirements
• microSD or SD card
• Computer, tablet, laptop, or smartphone equipped with a USB-C or
USB-A port
Note: To obtain the maximum USB throughput, you must use a
system with a USB 3.0 port.
The SDMSDRWU3AC is OS independent and doesn’t require any
additional drivers or software.
The card reader/writer receives enough power through the USB bus
and doesn’t require an additional power source.
Requirements are subject to change. For the latest requirements,
please visit www.StarTech.com/SDMSDRWU3AC.
SDMSDRWU3AC
USB 3.0 Memory Card Reader/Writer for SD and microSD cards - USB-C and USB-A
*actual product may vary from photos
Introduction
The SDMSDRWU3AC provides a quick and easy way to access
data stored on SD™ cards and microSD™ cards, and supports data
transfer speeds up to 5Gbps. You can use this card reader/writer
with a computer, tablet, laptop, or smartphone that’s enabled with a
USB-C™ or USB-A port.
Product diagram
Removable end cap
USB-C connector
(not pictured)
USB-A connector
(not pictured)
Activity LED
microSD card slot
SD card slot
Removable end cap
About USB 3.0 and USB 3.1 Gen 1
USB 3.0 is also known as USB 3.1 Gen 1. This connectivity standard
oers speeds up to 5Gbps. Any mention of USB 3.0 in this manual or
on the StarTech.com website in relation to SDMSDRWU3AC refers to
the 5Gbps USB 3.1 Gen 1 standard.
Note: Data transfer rates are dependent upon the speed of the
memory card you are using and the speed capabilities of the USB
port on your device.
About the LED indicator
The SDMSDRWU3AC features a blue Activity LED located to the
left of the card slots. The Activity LED blinks to indicate that data is
being transferred.
Avoid disconnecting the card reader/writer when the Activity LED is
blinking.
Connect the card reader/writer
1. Gently slide a memory card into the appropriate card slot on the
SDMSDRWU3AC until you feel resistance and the card is fully
inserted.
2. Do one of the following:
• Insert the USB-C connector on the card reader/writer into the
USB-C port on your computer, tablet, laptop, or smartphone.
• Insert the USB-A connector on the card reader/writer into the
USB-A port on your computer, tablet, or laptop.
3. To access the content on your memory card, follow the
instructions specic to the operating system that you’re running.
When you connect the card reader/writer, your system automatically
detects and installs the required software.
Caution! Do not insert two cards into the card reader/writer at the
same time. You can only access the data stored on one card at a time.
Problemløsning StarTech.com SDMSDRWU3AC
Hvis du har læst manualen omhyggeligt, men ikke fundet en løsning på dit problem, bed andre brugere om hjælp
Specifikationer
| Bredde: | 20 mm |
| Dybde: | 78 mm |
| Højde: | 11 mm |
| Vægt: | 11.8 g |
| Produktfarve: | Sort |
| Pakkevægt: | 38 g |
| Pakkedybde: | 105 mm |
| Pakkebredde: | 70 mm |
| Pakkehøjde: | 20 mm |
| Kompatible hukommelseskort: | MMC, MicroSD (TransFlash), MicroSDHC, MicroSDXC, SD, SDHC, SDXC |
| Opbevaringstemperatur (T-T): | -20 - 70 °C |
| Relativ luftfugtighed ved drift (H-H): | 50 - 90 % |
| Driftstemperatur (T-T): | 0 - 50 °C |
| Husmateriale: | Plast |
| Hurtig start guide: | Ja |
| Certificering: | CE, FCC, RoHS |
| LED-indikatorer: | Activity, Power |
| Harmoniseret systemkode (HS): | 84719000 |
| Hovedkassen højde (udvendigt): | 175 mm |
| Hovedkassens længde (udvendigt): | 425 mm |
| Hovedkassens bredde (udvendigt): | 290 mm |
| Intern: | Ingen |
| Maksimal størrelse på hukommelseskort: | 2000 GB |
| Plug and play: | Ja |
| Produkter pr. hovedkasse (udvendigt): | 100 stk |
| Dataoverførselshastighed: | 5000 Mbit/s |
| Organisering af chips: | Genesys Logic - GL3224 |
