Metra. The World’s Best Kits.
®
MetraOnline.com © COPYRIGHT 2019 METRA ELECTRONICS CORPORATION REV. 4/16/19 INST99-7385B
INSTALLATION INSTRUCTIONS
99-7385B
Attention! Let the vehicle sit with the key
out of the ignition for a few minutes before
removing the factory radio. When testing the
aftermarket equipment, ensure that all factory
equipment is connected before cycling the
key to ignition.
KIT FEATURES
KIT COMPONENTS
• A) Radio trim panel • B) Radio brackets • C) Climate display • D) Pocket • E) (12) #8 x 3/8” Phillips screws • F) Wiring harness (not shown)
TOOLS REQUIRED
• Panel removal tool • Phillips screwdriver • Wire
cutter • Crimp tool • Solder gun • Tape • Connec-
tors (example: butt-connectors, bell caps, etc.)
TABLE OF CONTENTS
Dash Disassembly ..................................................2
Kit Assembly
–ISO DIN radio provision with pocket ..................3
–ISO DDIN radio provision .....................................3
Wiring Instructions ............................................4-5
Installation .............................................................5
Final Assembly .......................................................6
(ASWC-1) steering wheel control settings .......6-10
WIRING & ANTENNA CONNECTIONS
(sold separately)
Wiring Harness: Included with kit
Antenna Adapter: Included with kit
Steering wheel control interface: ASWC-1 Included with kit
12v to 6v camera stepdown: AX-CAM6V included with kit
A B C D E
Hyundai Santa Fe
(without NAV)
2017-2018/
Santa Fe Sport
(without NAV, with display radio†)
2017-2018
• ISO DIN radio provision with pocket
• ISO DDIN radio provision
• Includes climate display and ASWC-1
• Retains audio controls on the
steering wheel
• Retains the factory backup camera
• Provides NAV outputs (speed sense)
• Includes an AX-CAM6V 12 TO 6V
stepdown
• Painted matte black
† Display radio is an Android Auto / Apple CarPlay radio
