MERCEDES BENZ
2015 - 2016 A-class (W176)
2015 - 2016 B-class (W24)
2015 - 2017 C-class (W205)
2015 - 2016 E-class (W212)
2015 - 2016 CLA (C117)
2015 - 2016 CLS (W218)
2015 - 2016 GLA (X156)
2015 - 2016 GLC (X205)
Rear-view camera input with Dynamic Guide Lines
Control by factory infotainment
On-screen display and setup
2 trigger outputs (+12V max. 1A), separately adjustable switching events (CAN, ACC, rear-view camera,
reverse gear)
Front camera input
Front camera input can also be used as an Auxiliary Video Input (Crux part# AUX-MB2, OBD2 Audio Aux
coding, may be required to create an Auxiliary Audio Input) (Sold separately).
Automatic switching to rear-view camera input on engagement of reverse gear from all operation modes
Forced rear-view camera option
Manual return from rear-view and front camera (cancellation of automatic switching)
Compatible with all factory video accessories (e.g. rear-view camera, DVD-changer, etc.)
Plug & Play installation
COMAND Online NTG5/5.1, Audio20 NTG5/5.1 with 4pin HSD LVDS connector on the monitor
1 / 12
Rev.051916
Interface Box
MB-78N Harness
Power/CAN Harness
LVDS1 OUT (Female to Female)
LVDS IN (Male to Female)
