Side 1/6
- Retains factory features in select GM LAN 29 Bit vehicles while func oning with an rmarket ae
radio.
- Pre-programmed to retain factory Steering Wheel Controls.
- Retains OnStar, factory Rear view camera and chime funcons.
- Adds Forced Rear view and Front view camera while in mo on using the factory side mirror
controls.
- Su orts Bose, non-Bose a Y-91 audio systems. pp nd
- EIA color coded wiring for easy installa on.
1. The Front and Rear fading are not retained on Y- Bose System. 91
2. Chime includes: seat belt,
check e ine, key in igni on, low fuel, low oil and lights on. ng
SOOGM-16W Mo le du
SOOGM-16W arness H
Video Harness
Antenna Adaptor
SWC Cable
SETTING THE AFTERMARKET R IO BRAND AD
With the key in the o pos on, set the DIP switches to the correspo ing a rmarket radio se ng. ff i nd e
3.5 SWC CABLE MM
Plug in the 4-Pin SWC cable to the 4-pin c ector plug the module. onn on
NOTE: C or insulate the 3.5mm plug, the Blue/Yellow or Gr n wires if not being used.ap ee
SWC 3.5MM PLUG ADAPTER:
-
Supports Rear Entertainment System with special order harness # A2444
Crux Interfacing Solutions • 21541 Nordhoff St., Unit C, Chatsworth, CA 91311
phone: (818) 609-9299 • fax: (818) 996-8188 • www.cruxinterfacing.com
1 of 6
rev.03282023
RSE Retention
Harness
