Crux Interfacing Solutions • 6860 Canby Ave., Suite 104, Reseda, CA 91335
phone: (818) 609-9299 • fax: (818) 996-8188 • www.cruxinterfacing.com
rev.021919
VIMVL-98B
VIM Activation for Select
VOLVO Vehicles with Sensus 2014 Navigation System
1 of 2
- Retains funconality of Factory-installed Navigaon System for passenger access at anyme
- Allows onscreen access to Factory Bluetooth Keypad*
- Allows for Navigaon Desnaon Address Entry at anyme*
- Designed for OEM equipment only
*Subject to capability of Factory-installed Navigaon System.
PRODUCT FEATURES:
R
INTERFACING SOLUTIONS
Sightline
VIDEO IN-MOTION ACTIVATION
PARTS INCLUDED:
VIMVL-98B MODULE VIMVL-98B HARNESS
INSTALLATION DIAGRAM:
Installaon of the VIMVL-98B is done at the factory navigaon unit Quadlock connector.
TO FACTORY
NAVIGATION
UN
FROM FACTORY
NAVIGATION HARNESS
DP
ON
DIP
SWITCH
LED*
*LED RED = Power ON Status
LED BLUE = Data Bus ON Status
8-Pin Molex
GREEN WIRE
NON PERMANENT
ACTIVATION OF VIDEO BYPASS
(See VIM Activation on page 2)
+12V ACC
(Toggle switch NOT included)
