Crux Interfacing Solutions • Chatsworth, CA 91311
phone: (818) 609-9299 • fax: (818) 996-8188 • www.cruxinterfacing.com
rev.113020
SOOGM-15V
Radio Replacement with OnStar, SWC Retention and
Video Switcher for GM Class II Vehicles
1 of 4
RAD IO REP LAC EME NT
SWC RE TEN TIO N
+
R
INTERFACING SOLUTIONS
PRODUCT FEATURES:
- Retains factory features in select GM Class II vehicles while funconing with an aermarket radio.
- Pre-programmed to retain factory Steering Wheel Controls.
- Retains OnStar and chime funcons.
- Adds Forced front and rear aermarket camera inputs while in moon using the SOURCE DOWN or AM/FM buon on the
steering wheel controls on select vehicles.
- Supports Bose, non-Bose and Y-91 audio systems.
- EIA color coded wiring for easy installaon.
1. The Front and Rear fading are not retained on Y-91 Bose System.
2. Chime includes: seat belt, check engine, key in ignion, low fuel, low oil and lights on.
NOTES:
SOOGM-15V Module SOOGM-15V Harness Video Harness Antenna Adaptor SWC Cable
SETTING THE AFTERMARKET RADIO BRAND
With the key in the o posion, set the DIP switches to the corresponding aermarket radio seng:
RADIO BRAND: DIP#: 1 2 3 4
Atoto, Dual, Fahrenheit, Jensen,
Pioneer, Power Acoustik, Soundstream
Blaupunkt, Most o-brand Radio
Alpine
Clarion
Kenwood
JVC
Boss, Old Sony
New Sony
NOTE: For Atoto, Blaupunkt, Dual, Farenheit, Power Acoustik, Soundstream, and most o-brand radios,
check the aftermarket radio’s manual to see if the SWC buttons need to be programmed.
SWC MODULE
DIP SWITCH
1 2 3 4
ON
OFF OFF ON ON
OFF OFF ON ON
OFF OFF ON ON
OFF OFF OFF OFF
OFF ON ON OFF
OFF ON ON ON
OFF ON OFF ON
OFF ON OFF OFF
OFF OFF ON OFF
PARTS INCLUDED:
DIP SWITCH SETTINGS:
3.5MM SWC CABLE
Plug in the SWC cable to the SWC module and the 3.5mm plug to the aermakert radio SWC port or use the Blue/Yellow wire
for JVC and Kenwood.
RED to SWC Key 1
WHITE to SWC Key 2
SHIELD to SWC Ground
For aermarket radios that have wires for SWC connecons, cut o the 3.5mm plug on the Crux SWC Cable (opon B) and
connect the SWC wires as follows:
Note that there are some radios that only have
SWC1 and SWC2, in this case “shield” does not
need to be connected.
