Side 1/12
• With OE type Dynamic Parking Guide Lines
• On-screen display and setup
• 2 trigger outputs (+12V max. 1A), separately adjustable switching events (CAN, ACC,
rear-view camera, reverse gear)
• Rear-view camera input
• Front camera input
• Front camera input can also be used as an Auxiliary Video Input
• Automatic switching to rear-view camera input on engagement of reverse gear from all
operation modes
• Forced rear-view camera option (only on vehicles with PDC button)
• Manual return from rear-view and front camera (cancellation of automatic switching)
• Picture-in-picture mode combining after-market rear-view and front camera picture(s)
with factory parking sensor graphics
• Compatible wi all factory video accessories (e.g. rear-view camera, DVD-changer, etc.) th
• Plug & Play installation
• For the F-series BMW with NBT navigation system or radio, 6.5”, 7”, 8.8” or 10.25”
monitor and 4+2pin HSD2 LVDS connector.
• On i3 installations, part# HAR-i3 is required to install the interface. The interface module
is installed/mounted under the rear seat and you will need to run the HAR-i3 towards
the rear seat.
CS-BMW6 Module
CS-BMW6 Harness
4+2 PIN HSD2 LVDS Cable
Power/CAN Harness
1 / 12
rev.060519
