INSTRUCTION MANUAL
GOOSENECK PAGING MICROPHONE - - DM 518 AM
Thank you for purchasing TOA’s Paging Microphone.
Please carefully follow the instructions in this manual to ensure long, trouble-free use of your equipment.
1. GENERAL DESCRIPTION
The -518- is a gooseneck paging microphone with push- -talk switch and remote control output. DM AM to
The microphone body is solidly constructed of metal -cast and designed to reduce switching and handling noise. die
2. APPEARANCE
3. CIRCUIT DIAGRAM
4. SPECIFICATIONS
Type
Moving coil microphone
Directivity
Unidirectional
Frequency Response
50 ,000 Hz –12
Sensitivity
-63 3 dB (0 dB=1V/Pa, 1kHz) dB ±
Rated Impedance
150 , balanced Ω
Talk Switch
Short-o circuit type, push- -talk switch (Normally-Open) to
Connection Cable
4 conductor (1 shielded) cable
Finish
Body: D -cast zinc, painted Metallic Gray ie
Head: Die-cast aluminum and zinc plated steel wire, painted Metallic Gray
Gooseneck: High carbon steel and aluminum alloy, electroplating Bright Chrome
Dimensions
Φ Φ1.56” x 6.38”] 39.5 62 [x 1 mm (Microphone body)
Weight
7 g (including connection cable)20
Accessories
Mounting screws … 3 (3/4” length)
Note: The design and specications are subject to change without notice for improvement.
202210
Base part
*detachable with 5/8” thread
Gooseneck part
Push- -talk switch to
