INSTRUCTION MANUAL
TIE-CLIP MICROPHONE YP-M101
Thank you for purchasing TOA’s Tie-Clip Microphone.
Please carefully follow the instructions in this manual to ensure long, trouble-free use of your equipment.
URL: http://www.toa.jp/
133-05-307-8A
1. GENERAL DESCRIPTION
The YP-M101 is a tie-clip type microphone designed
to be exclusively used with an optional WM-1100
Portable Transmitter.
2. NOMENCLATURE
3. CLIP ATTACHMENT
Attach the supplied clip as shown in the gure.
4. HOW TO USE
• Keep the microphone 15 – 20 cm away from the
mouth when using.
• Take care not to speak loud or position the
microphone too close (within 5 cm) to the mouth,
because this could mufe sounds and make them
inaudible.
5. SPECIFICATIONS
Type Electret condenser type
Directivity Unidirectional
Sensitivity –46 dB (0 dB=1 V/Pa,
1 kHz, load: 2 kΩ)
Maximum Input Sound
Pressure
115 dB SPL
Terminal ø3.5 mm monaural plug
Cord Length 80 cm
Finish Dark gray
Weight 20 g (cable included)
Note: The design and specications are subject to
change without notice for improvement.
• Accessory
Clip ............................................................ 1
Clip
3.5 mm-diameter monaural plug
Microphone
This portion rotates 360º.
Problemløsning TOA YP-M101
Hvis du har læst manualen omhyggeligt, men ikke fundet en løsning på dit problem, bed andre brugere om hjælp
Specifikationer
| Type: | Clip-on mikrofon |
| Produktfarve: | Grå |
| Forbindelsesteknologi: | Ledningsført |
| Enhedsgrænseflade: | 3.5 mm (1/8") |
| Mikrofonretningstype: | Envejs |
| Mikrofon sensitivitet: | -46 dB |
| Mikrofon vægt: | 20 g |
| Svingspole type: | Kondensator |
| Mikrofonholder: | Ja |
