MICROPHONE DM-1100
1. GENERAL DESCRIPTION
The TOA DM-1100 is a unidirectional microphone suited for hand-held, general-use applications. This microphone
body is rigidly constructed of diecast-aluminum, and designed to reduce switching and handling noises.
2. APPEARANCE
Phone Plug
3. CIRCUIT DIAGRAM
ON
OFF
PhonePlug
4. SPECIFICATIONS
Model DM-1100
Type Moving coil microphone
Directivity Unidirectional
Rated Impedance 600 Ω, unbalanced
Rated Sensitivity –55 dB (1 kHz, 0 dB=1 V/Pa)
Frequency Response 100 Hz to 12 kHz
Connection Cable 1-core shielded cable
Cable Length 7.5 m or 24.6 ft
Terminal of Cable Phone plug
Weight 155 g or 0.34 lb (without connection cable)
Dimensions ø 55 x 178 mm or ø 2.2 x 7.0 in
Talk Switch Short-off circuit type, slide switch
Finish Body: Diecast-alminum, painted Black
Head: ABS resin, Black / Zinc plated steel wire, painted Black
Standard Accessory Microphone holder (W5/16", W5/8")
Note: The design and specications are subject to change without notice for improvement.
URL: http://www.toa.jp/
133-04-00008-00
INSTRUCTION MANUAL
Problemløsning TOA DM-1100
Hvis du har læst manualen omhyggeligt, men ikke fundet en løsning på dit problem, bed andre brugere om hjælp
Specifikationer
| Højde: | 178 mm |
| Produktfarve: | Sort |
| Husmateriale: | Acrylonitrile butadiene styrene (ABS), Aluminium |
| Forbindelsesteknologi: | Ledningsført |
| Kabellængde: | 7.5 m |
| Diameter: | 55 mm |
| Mikrofonindgangsimpedans: | 600 ohm (Ω) |
| Mikrofon frekvens: | 100 - 12000 Hz |
| Mikrofonretningstype: | Envejs |
| Mikrofon sensitivitet: | -55 dB |
| Mikrofon vægt: | 155 g |
| Antal produkter inkluderet: | 1 stk |
