Quick-Start Guide
To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.
Manual Revision: September 3, 2021 3:41 PM
Product Diagram (TB4CDOCK / TB4CDOCKUE)
Front
Port Function
1SD Card Slot
• Secure Digital (SD) 4.0 UHS-II, SD 3.0, 2.0, 1.1, and 1.0
compatibility
• Push an , label side up, into the until it SD Card SD Card Slot
clicks into place
Note: The Host Computer’s Operating System (OS) will
automatically detect the SD Card and install the required
driver software.
• Push then pull the to removeSD Card
2USB-A Charge Port
• USB 2.0 (480 Mbps)
• BC 1.2 Maximum 7.5W (5V/1.5A) power output
• Connect a and/or (e.g. USB-A Peripheral Storage Devices
ash drives), using USB Cables
33.5mm Audio Port • Connect an Audio Device
• 4 Position TRRS Audio Jack Headsetfor use
4Thunderbolt 4 Host
Port
• Thunderbolt 4
• Connect/charge the Host Computer
Note: A maximum of 96 watts of Power Delivery is
available for the Host Computer.
5Power LED Indicator
• Solid White LED Docking Stationindicates the is receiving
power and is powered ON
• Solid Green LED Docking Stationindicates the is
connected to a Host Computer
Thunderbolt 4 / USB4™ Docking Station - Dual 4K 60Hz Display - Single 5K/8K - Up to 96W Power Delivery
Side
Port Function
6Lock Slot
• Lock the to a secure stationary objectDocking Station
7Nano Lock Slot
Rear
Port Function
8DC 20V Port • Connect the to power the Universal Power Adapter
Docking Station
9Thunderbolt 4
Device Ports (x3)
• Thunderbolt 4
• Supports Thunderbolt 4, Thunderbolt 3, USB-C devices and
up to two 4K monitors or a single 5K/8K monitor
• Supports DisplayPort and HDMI monitors (adapters sold
separately)
10 RJ45 Port • Connect to a 10/100/1000Mbps Network Device
11 USB-A Ports (x3)
• SuperSpeed USB 10Gbps (USB 3.2 Gen 2)
• Supports charging of up to 5V/0.9A per port
• Connect up to 3 SuperSpeed USB 10Gbps Peripherals
and/or (e.g. ash drive), using a Storage Devices
SuperSpeed USB-A 10Gbps (USB 3.2 Gen 2) Cable
1 2 3 4 5
6 7
810
911
Problemløsning StarTech.com TB4CDOCKUE
Hvis du har læst manualen omhyggeligt, men ikke fundet en løsning på dit problem, bed andre brugere om hjælp
Specifikationer
| Bredde: | 194 mm |
| Dybde: | 84 mm |
| Højde: | 29 mm |
| Vægt: | 1000 g |
| Produktfarve: | Black, Grey |
| Pakkevægt: | 1100 g |
| Pakkedybde: | 145 mm |
| Pakkebredde: | 230 mm |
| Pakkehøjde: | 90 mm |
| Kompatible hukommelseskort: | MMC, MicroSD (TransFlash), MicroSDHC, MicroSDXC, SD, SDHC, SDXC |
| HD-type: | 8K Ultra HD |
| Opbevaringstemperatur (T-T): | -20 - 70 °C |
| Relativ luftfugtighed ved drift (H-H): | 0 - 95 % |
| Ethernet LAN-porte (RJ-45): | 1 |
| Antal USB 2.0-porte: | 1 |
| Udgange til hovedtelefoner: | 1 |
| Ethernet LAN: | Ja |
| Driftstemperatur (T-T): | 0 - 50 °C |
| Ethernet LAN-datahastigheder: | 10,100,1000 Mbit/s |
| Husmateriale: | Aluminium, Plastic |
| Hurtig start guide: | Ja |
| Kabler inkluderet: | Thunderbolt |
| Forbindelsesteknologi: | Ledningsført |
| DC-in-stik: | Ja |
| LED-indikatorer: | Ja |
| AC-adapter inkluderet: | Ja |
| Kabellængde: | 0.8 m |
| Indbygget kortlæser: | Ja |
| Harmoniseret systemkode (HS): | 84733020 |
| Bæredygtighedscertifikater: | CE, RoHS |
| Slot til kabellås: | Ja |
| Understøttede Mac-operativsystemer: | Mac OS X 11.0 Big Sur, Mac OS X 13.0 Ventura |
| Hovedkassen højde (udvendigt): | 265 mm |
| Hovedkassens længde (udvendigt): | 305 mm |
| Hovedkassens bredde (udvendigt): | 380 mm |
| Værtsgrænseflade: | Thunderbolt 4 |
| Maksimal opdateringshastighed: | 60 Hz |
| Kabellåseslids type: | Kensington |
| Produkter pr. hovedkasse (udvendigt): | 8 stk |
| Fuld duplex: | Ja |
| Kombineret hovedtelefon/mikrofon-port: | Ja |
| Auto MDI/MDI-X: | Ja |
| USB strømforsyning: | Ja |
| Kompatible strømplug typer: | EU |
| Wake-on-LAN klar: | Ja |
| Antal USB 3.2 Gen 2 (3.1 Gen 2) type-A-porte: | 3 |
| Antal understøttede skærme: | 2 |
| USB strømforsyning op til: | 96 W |
| Thunderbolt 4 porte antal: | 3 |
| Chipsæt: | Intel - JHL8440, Cypress - CYUSB4357, Parade - FL5801, Parade - FL5801, Cypress - CYPD5235, Realtek - RTL8153B, Realtek - ALC4042, Genesys Logic - GL3226 |
