Quick-Start Guide
To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.
Manual Revision: February 8, 2021
1
2
3
4
5
6
Product Diagram (DKT30CHVPD2)
Front Angle View
Rear View
Port Specications and Installation
1 VGA Output Port
• Resolution of up to 1920x1080@60Hz
• Connect the Multiport Adapter to a VGA Display
Device, using a VGA M/M Cable
2 HDMI Output Port
• HDMI 1.4b
• 4K @ 30Hz
• Connect the Multiport Adapter to an HDMI Enabled
Display Device, using an HDMI Cable
USB-C™ Multiport Adapter - HDMI & VGA - 3 x USB - GbE- 100W PD - Extended Cable
3 RJ45 Port
• 10/100/1000 Mbps
• Connect the Multiport Adapter to a Network Device,
using a Network Cable
4 USB-A Charging Port
• SuperSpeed USB 5Gbps (USB 3.2 Gen 1)
• Maximum 1.5A for downstream charging
• Connect the Multiport Adapter to a SuperSpeed USB
5Gbps Peripheral or Storage Device (e.g. ash drive),
using a SuperSpeed USB 5Gbps (USB 3.2
Gen 1) Cable
5 USB-C Device Port
• SuperSpeed USB 5Gbps (USB 3.2 Gen 1)
• USB Power Delivery (PD) pass-through
• Connect the Host Computer’s Power Adapter
to the SuperSpeed USB-C Port on the Multiport
Adapter for a maximum of 85W delivered to the
Host Computer
Note: The Multiport Adapter accepts a 100W Power
Adapter and reserves 15W to power the Multiport
Adapter.
-- Or --
• Connect the Multiport Adapter to a SuperSpeed USB
5Gbps Peripheral or Storage Device (e.g. ash drive),
using a SuperSpeed USB-C 5Gbps (USB 3.2
Gen 1) Cable
6
USB-C Host
Connector
• SuperSpeed USB 5Gbps (USB 3.2 Gen 1)
• USB PD 3.0 85W (20V/5A)
Note: SuperSpeed USB-C Port will accept up to
100W Power Source input
• DP 1.2 Alt Mode
• Charge the Host Device while using the Multiport
Adapter
• Connect the Multiport Adapter to a to a Laptop,
using the SuperSpeed USB-C Host Connector
7 USB-A Device Port
• SuperSpeed USB 5Gbps (USB 3.2 Gen 1)
• Maximum 900mA downstream charging
• Connect the Multiport Adapter to a SuperSpeed USB
5Gbps Peripheral or Storage Device (e.g. ash drive),
using a SuperSpeed USB 5Gbps (USB 3.2
Gen 1) Cable
7
Problemløsning StarTech.com DKT30CHVPD2
Hvis du har læst manualen omhyggeligt, men ikke fundet en løsning på dit problem, bed andre brugere om hjælp
Specifikationer
| Bredde: | 310 mm |
| Dybde: | 52 mm |
| Højde: | 14 mm |
| Vægt: | 110 g |
| Brugervejledning: | Ja |
| Produktfarve: | Black, Grey |
| Pakkevægt: | 135 g |
| Pakkedybde: | 170 mm |
| Pakkebredde: | 142 mm |
| Pakkehøjde: | 30 mm |
| Opbevaringstemperatur (T-T): | -10 - 70 °C |
| Relativ luftfugtighed ved drift (H-H): | 10 - 85 % |
| Antal HDMI-porte: | 1 |
| Ethernet LAN-porte (RJ-45): | 1 |
| Antal USB 3.2 Gen 1 (3.1 Gen 1) type-A-porte: | 2 |
| Driftstemperatur (T-T): | 0 - 45 °C |
| Ethernet LAN-datahastigheder: | 10,100,1000 Mbit/s |
| Kabellængde: | 0.3 m |
| Harmoniseret systemkode (HS): | 84719000 |
| Bæredygtighedscertifikater: | CE, RoHS |
| Understøttede Windows-operativsystemer: | Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 IoT Enterprise, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64 |
| Understøttede Mac-operativsystemer: | Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.15.3 Catalina, Mac OS X 11.0 Big Sur, Mac OS X 13.0 Ventura |
| Andre understøttede operativsystemer: | ChromeOS |
| Hovedkassen højde (udvendigt): | 200 mm |
| Hovedkassens længde (udvendigt): | 340 mm |
| Hovedkassens bredde (udvendigt): | 450 mm |
| Værtsgrænseflade: | USB 3.2 Gen 1 (3.1 Gen 1) Type-C |
| Antal VGA-porte (D-sub): | 1 |
| Produkter pr. hovedkasse (udvendigt): | 30 stk |
| Ethernet-grænsefladetype: | Fast Ethernet, Gigabit Ethernet |
| Antal USB 3.2 Gen 1 (3.1 Gen 1) type-C-porte: | 1 |
| Dataoverførselshastighed: | 5000 Mbit/s |
| USB strømforsyning revision: | 3.0 |
| USB strømforsyning: | Ja |
| Porte, antal: | 6 |
| USB strømforsyning op til: | 100 W |
| Hub-grænseflader: | HDMI, RJ-45, USB 3.2 Gen 1 (3.1 Gen 1) Type-A, USB 3.2 Gen 1 (3.1 Gen 1) Type-C, VGA |
| Maksimal opløsning (HDMI): | 3840 x 2160 pixel |
| Chipsæt: | AG6320, FL5001, FL7102, RTL8153 |
