Instruction Manual
DE: Bedienungsanleitung - de.startech.com
FR: Guide de l'utilisateur - fr.startech.com
ES: Guía del usuario - es.startech.com
IT: Guida per l'uso - it.startech.com
NL: Gebruiksaanwijzing - nl.startech.com
PT: Guia do usuário - pt.startech.com
Manual Revision: 10/07/2013
For the most up-to-date information, please visit: www.startech.com
Packaging Contents
• 1 x mSATA to SATA Adapter
• 2 x Installation Screws
• 1 x Instruction Manual
System Requirements
• SATA Hard Drive
• Computer System with:
Available mSATA port on the motherboard
Available SATA Power connector on the power supply
MSAT2SAT3
mSATA to SATA port Adapter
*actual product may vary from photos
Product Overview
mSATA Port
SATA Port
Installation Holes
Adapter Installation
WARNING! Hard Drives and format adapters require careful
handling. If you are not careful with your Drive, lost data may result.
Always handle your drive with caution. Be sure that you are properly
grounded by wearing an anti-static strap when handling computer
components or discharge yourself of any static electricity build-up
by touching a large grounded metal surface (such as the computer
case) for several seconds.
1. Slide the mSATA to SATA adapter into the mSATA connector on
the system motherboard.
2. Secure the drive into place.
If the board has an installation clip, gently apply pressure to the
top center of the adapter until it locks into place on either side of
the SSD clip. To release the adapter refer to your motherboards
user manual for detailed instruction.
or
If the board has mounting holes. Drive each of the included
installation screws through the matching installation holes on the
adapter into the mounting holes on the motherboard.
3. The SATA port on the adapter now functions as a standard SATA
port to the specication of the motherboard’s mSATA port.
Problemløsning StarTech.com MSAT2SAT3
Hvis du har læst manualen omhyggeligt, men ikke fundet en løsning på dit problem, bed andre brugere om hjælp
Specifikationer
| Bredde: | 30 mm |
| Dybde: | 51 mm |
| Højde: | 8 mm |
| Vægt: | 10 g |
| Brugervejledning: | Ja |
| Produktfarve: | Grøn |
| Pakkevægt: | 15 g |
| Pakkedybde: | 225 mm |
| Pakkebredde: | 125 mm |
| Pakkehøjde: | 10 mm |
| Opbevaringstemperatur (T-T): | -25 - 70 °C |
| Relativ luftfugtighed ved drift (H-H): | 20 - 80 % |
| Relativ luftfugtighed ved opbevaring (H-H): | 15 - 90 % |
| Driftstemperatur (T-T): | 5 - 50 °C |
| Harmoniseret systemkode (HS): | 84733020 |
| Bæredygtighedscertifikater: | CE, RoHS |
| Hovedkassen højde (udvendigt): | 215 mm |
| Hovedkassens længde (udvendigt): | 690 mm |
| Hovedkassens bredde (udvendigt): | 295 mm |
| Værtsgrænseflade: | mSATA |
| Intern: | Ja |
| Produkter pr. hovedkasse (udvendigt): | 100 stk |
| Skruer inkluderet: | Ja |
| Output-grænseflade: | SATA |
| Dataoverførselshastighed (maks.): | 6 Gbit/sek. |
| SATA revision: | 3.0 |
