Quick-Start Guide
To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.
Manual Revision: September 28, 2023 8:48 AM
Product ID
FCREADMICRO3V2
Component Function
1Micro SD Card Slot Insert a • Micro SD Card
2SD Card Slot Insert a • SD Card
3CF Card Slot Insert a • CompactFlash Card
4USB-C Host Connection Connect to a • USB-C Host
5USB-A to USB-C Adapter
• Connect the to a Memory Card Reader USB-A
Host
Product Information
For the latest drivers/software, technical specications, and declarations of conformance,
please visit: www.StarTech.com/FCREADMICRO3V2
USB 3.2 Gen 1 (5Gbps) Multi-Media Memory Card Reader
Requirements
• USB-A or USB-C Enabled Host Device x 1
• Memory Card
Package Contents
• Multi-Media Memory Card Reader x 1
• Quick-Start Guide x 1
Installation
WARNING! When removing media cards connected to Multi-Media Memory Card
Reader, it is required to remove/eject the device from within the operating system.
Failure to remove storage devices properly can result in lost data, or permanent
damage to the Memory Card or Card Reader.
Installing the Multi-Media Memory Card Reader
1. Insert a into the compatible Memory Card Media Card Slot.
Note: The Multi-Media Memory Card Reader supports read/write to all three drives
simultaneously.
2. (Optional) Connect the Multi-Media Memory Card Reader’s USB-A to USB-C
Adapter.
3. Connect the to an available or on the USB Host Connection USB-A USB-C Port Host
Computer.
4. The operating system will detect the and Multi-Media Memory Card Reader
automatically install the correct . Drivers
Card Support
This Multi-Media Memory Card Reader supports:
• Secure Digital v3.0 UHS-I
• SDR12
• SDR25
• SDR50
• DDR50
• SDR104
• CompactFlash 6.0
• UltraDMA Mode 7
• PIO Mode 6
3
1 2
4
5
Problemløsning StarTech.com FCREADMICRO3V2
Hvis du har læst manualen omhyggeligt, men ikke fundet en løsning på dit problem, bed andre brugere om hjælp
Specifikationer
| Bredde: | 389 mm |
| Dybde: | 28 mm |
| Højde: | 15 mm |
| Vægt: | 45 g |
| Antal pr. pakke: | 1 stk |
| Produktfarve: | Grå |
| Pakkevægt: | 45 g |
| Pakkedybde: | 125 mm |
| Pakkebredde: | 225 mm |
| Kompatible hukommelseskort: | CF Type II, MicroSD (TransFlash), MicroSDHC, MicroSDXC, SD, SDHC, SDXC |
| Opbevaringstemperatur (T-T): | -10 - 70 °C |
| Relativ luftfugtighed ved drift (H-H): | 10 - 85 % |
| Driftstemperatur (T-T): | 0 - 45 °C |
| Hurtig start guide: | Ja |
| Kabellængde: | 0.3 m |
| Bæredygtighedscertifikater: | RoHS |
| Hovedkassen højde (udvendigt): | 210 mm |
| Hovedkassens længde (udvendigt): | 320 mm |
| Hovedkassens bredde (udvendigt): | 500 mm |
| Intern: | Ingen |
| Produkter pr. hovedkasse (udvendigt): | 200 stk |
| Overholdelse af bæredygtighed: | Ja |
| Dataoverførselshastighed: | 5000 Mbit/s |
| Antal hukommelseskortholdere: | 3 |
| Grænseflade-adaptere inkluderet: | USB Type-C - USB Type A |
| Organisering af chips: | AU84610 |
