Instruction Manual

DE: Bedienungsanleitung - de.startech.com

FR: Guide de l'utilisateur - fr.startech.com

ES: Guía del usuario - es.startech.com

IT: Guida per l'uso - it.startech.com

NL: Gebruiksaanwijzing - nl.startech.com

PT: Guia do usuário - pt.startech.com

Manual Revision: 10/28/2011

For the most up-to-date information, please visit: www.startech.com

Packaging Contents

• CompactFlashtoZIF/LIFAdapter

• InstructionManual

ZIF2CF

1.8in ZIF LIF to Single Compact Flash SSD Adapter Card

*actual product may vary from photos

Installation

WARNING! Computerequipmentcanbeseverelydamagedbystaticelectricity.Besurethatyouareproperlygroundedbeforeopening

yourcomputercaseortouchingyourharddrive.StarTech.comrecommendsthatyouwearananti-staticstrapwheninstallingany

computercomponent.Ifananti-staticstrapisunavailable,dischargeyourselfofanystaticelectricitybuild-upbytouchingalarge

groundedmetalsurface(suchasthecomputercase)forseveralseconds.Besuretohandleyourharddrivecarefullyandconsultyourhard

driveandlaptopmanufacturerfordetailsonhowtoremovethedrive.



WARNING! TheZIF2CFadapterdoesnotsupporthot-swapping.Pleaseensurethatthehostcomputerispowereddownwhenconnecting

ordisconnectingtheCompactFlashcardtoorfromtheadapter.Similarly,pleaseensurethatthehostcomputerispowereddownwhen

connecting/removingtheadapter,whenaCompactFlashcardisconnectedtotheadapter.

Please note:Tosimplifyinstallation,powerdownthecomputerorZIF/LIFdeviceintowhichtheadapterwillbeinstalled,andremovethe

existingZIF/LIFdevice.

1. WiththeCompactFlashcardlabelfacingupward(visible),aligntheholesontheconnectorendofthe

CompactFlashcardyouwishtoinstall,withthepinsprovidedbythebyZIF2CFadapter.

2. ApplygentlepressuretotheCompactFlashcard,untilthepinsprovidedbytheadapterarefullyinserted

intotheadapterconnectorholes.

3. Gently,liftthebrownleverfromtheZIF/LIFconnectoronZIF2CF,andinserttheZIF/LIFcablefromthe

device/computerintotheZIF2CFZIF/LIFconnector,suchthatPin#1onthetheZIF/LIFcableisaligned

withPin#1ontheZIF/LIFconnectorprovidedbytheZIF2CFadapter(denotedbywhitearrow).

ZIF/LIFConnector

ZIF/LIFPin#1

Marker

CompactFlash

Connector

Problemløsning StarTech.com ZIF2CF

Hvis du har læst manualen omhyggeligt, men ikke fundet en løsning på dit problem, bed andre brugere om hjælp

Specifikationer

Bredde:	54 mm
Dybde:	70 mm
Højde:	6 mm
Vægt:	16 g
Pakkevægt:	60 g
Værtsgrænseflade:	CompactFlash
Stik:	1x 50-pin, Type I & II CompactFlash / MicroDrive, 1x ZIF/LIF 40-pin
