Metra. The World’s Best Kits.
®
MetraOnline.com © COPYRIGHT 2021 METRA ELECTRONICS CORPORATION REV. 12/6/22 INSTDP-7529
INSTALLATION INSTRUCTIONS
DP-7529
Attention! With the key out of the ignition,
disconnect the negative battery terminal
before installing this product. Ensure that all
installation connections are secure before
cycling the ignition to test this product.
KIT FEATURES
• ISO DIN radio provision with pocket
• ISO DDIN radio provision
• Textured to match the factory dash.
• Can also be used as a factory dash replacement with factory
Mazda radios.
KIT COMPONENTS
• A) Radio housing • B) Radio trim panel • C) Radio brackets • D) Pocket • E) #8 x 3/8” Truss-Head Phillips screws (8) • F) Panel clips (2)
• G) #8 x 1/2” Phillips screws (2)
TOOLS REQUIRED
• Panel removal tool • Phillips screwdriver
WIRING & ANTENNA CONNECTIONS
(sold separately)
Wiring Harness: 70-7901
Visit metraonline.com for audio/video and steering
wheel control interface options.
Antenna Adapter: Not required
A B C D
F G
E
Mazda Miata 1994-1997
Visit MetraOnline.com for more detailed information about the product and up-to-date vehicle
specific applications
TABLE OF CONTENTS
Dash Disassembly...............................................2-3
Kit Preparation .......................................................4
Kit Assembly
–ISO DIN radio provision with pocket ..................5
–ISO DDIN radio provision.....................................6
