Metra. The World’s Best Kits.
®
MetraOnline.com © COPYRIGHT 2024 METRA ELECTRONICS CORPORATION REV. 3/22/24 INST109-KI1HG
I N S TA L L AT I O N I N S T R U C T I O N S
109-KI1HG
Patent Pending
ATTENTION: With the key out of the
ignition, disconnect the negative battery
terminal before installing this product. Ensure
that all installation connections, especially the
air bag indicator lights, are plugged in before
reconnecting the battery or cycling the ignition
to test this product.
NOTE: Refer also to the instructions included
with the aftermarket radio.
KIT FEATURES
• Engineered exclusively for the new 9-inch Pioneer
®
Modular
Solutions Receiver (DMH-WC6600NEX) Radio
*See radio manufacturer for current models.
• Both textured and painted gloss black to match the factory finish.
KIT COMPONENTS
A) Radio housing front • B) Radio housing back • C) Pioneer brackets • D) (2) panel clips • E) (4) #8 x 3/8” Phillips screws
TOOLS REQUIRED
• Panel removal tool • Phillips screwdriver
• 10mm socket
TABLE OF CONTENTS
Dash Disassembly 2-3 ..............................................
Kit Preparation 4 .......................................................
Kit Assembly 5-6 ......................................................
Kia Seltos 2021-2023
Visit for more detailed information about the product and up-to-date vehicle MetraOnline.com
specific applications
A CB D E
WIRING & ANTENNA CONNECTIONS
Wiring Harness:
Visit metraonline.com for audio/
video and steering wheel control interface options.
Antenna Adapter: 40-KI11
