INSTXSVI-6502-NAV
© COPYRIGHT 2004-2013 METRA ELECTRONICS CORPORATION
1-800-221-0932 metraonline.com
REV. 4/15/14
XSVI-6502-NAV
2004-2010 Chrysler accessory and NAV output CAN harness
• Providesaccessory(12volt10amp)
• RetainsR.A.P.(retainedaccessorypower)
• Usedinnon-amplifiedsystems,orwhenreplacingamplifiedsystem
• Provides outputs(parkingbrake,reverse,andV.S.S.)NAV
• PrewiredASWC-1harnessincluded(ASWC-1soldseparately)
• Highlevelspeakerinput
• USBupdatable
CHRYSLER
300 2005-2007
Aspen 2007
PT Cruiser 2006-2010
DODGE
Caliber 2007-2008
Charger 2006-2007
Dakota 2005-2007
Durango 2004-2007
Magnum 2005-2007
Ram 1500 2006-2008
Ram 2500/3500 2006-2009
JEEP
Commander 2006-2007
Compass 2007-2008
Grand Cherokee 2005-2007
Patriot 2007-2008
MITSUBISHI
Raider 2006-2007
APPLICATIONS
WIRING THE XSVI-6502-NAV
• Connect the Yellowwire to the radio’s 12 volt battery or memory wire.
• Connect the wire to the radio’s ground wire. Black
• Connect the wire to the ignition wire of the aftermarket radio. Red
• Connect the wire to the illumination wire of the aftermarket radio. If the Orange
aftermarket radio has no illumination wire, tape off the wire. Orange
• Connect the wire to the antenna turn on wire of the aftermarket radio. Blue
• Connect the wire to the White left front positive speaker output of the aftermarket radio.
