Side 1/4
REV. 4/20/2016 INST99-5832G
INSTALLATION INSTRUCTIONS FOR PART 99-5832G
METRA. The World’s best kits.
™
metraonline.com
© COPYRIGHT 2016 METRA ELECTRONICS CORPORATION
CAUTION!
All accessories, switches, climate controls panels,
and especially air bag indicator lights must be connected before
cycling the ignition. Also, do not remove the factory radio with
the key in the on position, or while the vehicle is running.
• ISO DIN radio provision with pocket
• ISO DDIN radio provision
• Radio trim panel is painted gray
• A) Radio trim panel • B) Dash panel • C) Radio brackets • D) Pocket • E) Airbag light blank
• F) (4) #8 x 3/8” Phillips truss head screws • G) (2) #8 x 3/8” Phillips pan head screws • H) (3) Metal “U” panel clips
• I) (5) Metal “D”
panel clips • J) (4) Small metal “D” panel clips • K) (4) Plastic panel clips
KIT FEATURES
KIT COMPONENTS
• Panel removal tool • Phillips screwdriver
• Socket wrench • T-20 Torx screwdriver
TOOLS REQUIRED
Ford Transit 2015-up
(without 4.2” screen)
99-5832G
A
Table of Contents
B DC
F G
H I J K
E
Dash Disassembly ..................................................2
Kit Preparation ........................................................2
Kit Assembly
– 3 ISO DIN radio provision with pocket .......................
– 3 ISO DDIN radio provision .......................................
Final Assembly .......................................................3
WIRING & ANTENNA CONNECTIONS (sold separately)
Wire harness: • 70-5524 Antenna adapter: • 40-EU10
