METRA - The World’s best kits
®
metraonline.com
REV. 3/7/2017 INST99-8214
Installation instructions for part 99-8214
®
CAUTION!
All accessories, switches, climate controls panels, and
especially air bag indicator lights must be connected before cycling
the ignition. Also, do not remove the factory radio with the key in the
on position, or while the vehicle is running.
© COPYRIGHT 2017 METRA ELECTRONICS CORPORATION
• DIN radio provision with pocket
• ISO DIN radio provision with pocket
• ISO DDIN radio provision
• Painted and textured to match factory dash
• Available in: Black 99-8214TB or Gray 99-8214TG
• Both kits are factory “golf ball” textured
KIT FEATURES
WIRING & ANTENNA CONNECTIONS (sold separately)
Wiring Harness: 70-1761 • TYTO-01
Antenna Adapter: Not Required
Steering wheel control interface: ASWC-1
• Panel removal tool • Phillips screwdriver
• 10mm socket wrench
TOOLS REQUIRED
Toyota Tacoma 2005-2011
99-8214
• A) Radio housing • B) Radio brackets • C) Radio trim panel • D) ISO brackets • E) ISO trim plate
• F) ISO DDIN trim plate • G) Clock/Hazard switch bracket • H) (4) #6 x 3/8” Phillips pan-head screws
• I) (4) #8 X 3/8” Phillips truss-head screws • J) (1) #10 x 3/4” Phillips pan-head screw • K) (4) Panel clips
• L) Plastic threaded insert
KIT COMPONENTS
B C D
E F
A
I J K LG
H
Dash Disassembly ..................................................2
Kit Preparation ........................................................ 3
Kit Assembly
– DIN radio provision with pocket .............................4
– ISO DIN radio provision with pocket .......................5
– ISO DDIN radio provision ........................................ 6
Table of Contents
