Metra. The World’s Best Kits.
®
MetraOnline.com © COPYRIGHT 2019 METRA ELECTRONICS CORPORATION REV. 5/15/19 INST99-5719
INSTALLATION INSTRUCTIONS
99-5719
Attention! Let the vehicle sit with the key
out of the ignition for a few minutes before
removing the factory radio. When testing the
aftermarket equipment, ensure that all factory
equipment is connected before cycling the
key to ignition.
KIT FEATURES
• DIN radio provision with pocket
• ISO DIN radio provision with pocket
• ISO DDIN radio provision
• Integrated auto climate controls and display
• Integrated passenger airbag light
• Painted scratch resistant matte black
KIT COMPONENTS
• A) Radio housing • B) ISO Brackets • C) ISO trim plate • D) Pocket • E) ISO DDIN brackets • F) ISO DDIN trim plate • G) Temperature sensor housing
• H) Wiring harness (not shown)
TOOLS REQUIRED
• Radio removal tool (Metra part #86-5618)
• Phillips screwdriver • Panel removal tool
• Cutting tool • T-10 torx screwdirver
TABLE OF CONTENTS
Dash Disassembly ..................................................2
Kit Preparation .......................................................3
Kit Assembly
–DIN radio provision with pocket ........................4
–ISO DIN radio provision with pocket ..................5
–ISO DDIN radio provision .....................................6
Audio Wiring ..........................................................7
WIRING & ANTENNA CONNECTIONS
Wiring Harness: Included with kit
Antenna Adapter: Included with kit
A
F G
B C D E
Ford Taurus / Mercury Sable
(with auto climate) 2004-2007
Visit MetraOnline.com for more detailed information about the product and up-to-date vehicle
specific applications
