AXDIS-HK4
INSTALLATION INSTRUCTIONS
AxxessInterfaces.com © COPYRIGHT 2020 METRA ELECTRONICS CORPORATION REV. 1/22/20 INSTAXDIS-HK4
Attention! Let the vehicle sit with the key
out of the ignition for a few minutes before
removing the factory radio. When testing the
aftermarket equipment, ensure that all factory
equipment is connected before cycling the
key to ignition.
INTERFACE FEATURES
INTERFACE COMPONENTS
TOOLS REQUIRED
• Crimping tool and connectors, or solder gun,
solder, and heat shrink • Tape • Wire cutter
• Zip ties • Small flat-blade screwdriver
TABLE OF CONTENTS
Connections ............................................................2
Installation .............................................................3
Programming .........................................................3
Audio Level Adjustment ........................................3
Steering Wheel Control Settings
- L.E.D. feedback ....................................................4
- Changing radio type ...........................................4
- Remapping the steering wheel control buttons 5-6
- Dual assignment instructions (long button press) .6-7
Troubleshooting .....................................................7
Hyundai/Kia Data Interface with SWC 2010-2013
APPLICATIONS
• Provides NAV outputs (park
brake, reverse, speed sense)
• Retains audio controls on the
steering wheel
• Designed for amplified models
• Retains the factory AUX-IN jack
• Retains the factory backup
camera
• Retains balance
• Micro-B USB updatable
Hyundai
Tucson † 2010-2013
Kia
Forte ‡ 2010-2013
Sorento † 2011-2013
• AXDIS-HK4 interface • AXDIS-HK4 harness
• AXSP-HK interface • 16-pin harness with stripped leads
• Female 3.5mm connector with stripped leads
Visit AxxessInterfaces.com for more detailed information about the product and up-to-date
vehicle specific applications
† With NAV
‡ With auto climate control or NAV
