INSTALLATION INSTRUCTIONS
99-7382HG
Metra. The World’s Best Kits.
®
MetraOnline.com © COPYRIGHT 2024 METRA ELECTRONICS CORPORATION REV. 3/20/24 INST99-7382HG
ATTENTION: With the key out of the ignition,
disconnect the negative battery terminal before
installing this product. Ensure that all installation
connections, especially the air bag indicator lights, are
plugged in before reconnecting the battery or cycling
the ignition to test this product.
NOTE: Refer also to the instructions included with the
aftermarket accessory before installing this device.
KIT FEATURES
• ISO DIN radio provision with pocket
• ISO DDIN radio provision
• Includes SWC, antenna adapter, and wiring harness
• Retains the factory backup camera
• Includes a climate display to retain the information that was
displayed on the factory radio
• Includes a built-in hazard switch
• Painted high gloss black
KIT COMPONENTS
• A) Radio trim panel with climate display and hazard switch • B) Radio brackets • C) Pocket • D) (4) #8 x 3/8” Phillips screws
• Not Shown: Wiring harness, Antenna adapter
TOOLS REQUIRED
• Panel removal tool
• Phillips screwdriver
• 5/16” Socket wrench
• Wire cutter • Crimp tool
• Solder gun • Tape
• Connectors (example:
butt-connectors, bell caps, etc.)
TABLE OF CONTENTS
Dash Disassembly..................................................2
Kit Assembly
–ISO DIN radio provision with pocket.................. 3
–ISO DDIN radio provision .................................... 3
Wiring Instructions ...........................................4-12
Final Assembly....................................................... 7
WIRING & ANTENNA CONNECTIONS
Wiring Harness: Included with kit
Antenna Adapter: Included with kit
Steering Wheel Control Interface: Included with kit
12V-to-6V Camera Step-Down: Included with kit
A B
D
C
Kia Niro (without NAV) 2017-2019
Visit MetraOnline.com for more detailed information about the product and up-to-date vehicle
specific applications
