Ctek MXT 4.0 Brugsanvisning
Her er Ctek MXT 4.0 (Batterioplader) brugervejledning. 6 sider på sprog Engelsk med en vægt på 0.9 Mb. Hvis du ikke kan finde svar på dit problem Spørg vores community.
Side 1/6
EN
EN • 3
ABSORPTION, READY TO USE
ANALYSE
RECOND
RECOND
MODE
NORMAL
AGM
CONGRATULATIONS
to the purchase of your new professional switch mode battery charger.
This charger is included in a series of professional chargers from CTEK AB and SWEDEN
represents the latest technology in battery charging.
CTEK COMFORT CONNECT – eyelet M8
CTEK COMFORT CONNECT
MAINS CABLE
CTEK COMFORT CONNECT – clamp
CHARGE CABLE
SUPPLY PLUG*
*Supply plugs may dif fer to suit your wall socket.
NORMAL
BATTERY
PROGRAM
ERROR LAMP
AGM
BATTERY
PROGRAM
POWER
LAMP
CHARGING
1. Connect the charger to the battery.
2. Connect the charger to the wall socket. The power lamp will indicate that the mains
cable is connected to the wall socket. The error lamp will indicate if the battery clamps
are incorrectly connected. The reverse polarity protection will ensure that the battery
or charger will not be damaged.
3. Press the MODE-button to select charging program.
4. Follow the indication lamps through the charging process.
The battery is ready to start the engine when is lit.
The battery is fully charged when is lit.
5. Stop charging at any time by disconnecting the mains cable from the wall socket.
MODE-
BUT TON
MANUAL
DESULPHATION
SOFT START BULK FLOAT, FULLY CHARGED
PULSE, MAINTENANCE CHARGING
RECOND
PROGRAM
20015561D MXT 4.0, Manual EU, Print le 003.indd 3 2011-10-11 12:42:46
Problemløsning Ctek MXT 4.0
Hvis du har læst manualen omhyggeligt, men ikke fundet en løsning på dit problem, bed andre brugere om hjælp
Specifikationer
| Bredde: | 89 mm |
| Dybde: | 191 mm |
| Højde: | 48 mm |
| Vægt: | 800 g |
| Antal pr. pakke: | 1 stk |
| Produktfarve: | Blue, Silver |
| Batterispænding: | 2 V |
| Driftstemperatur (T-T): | -20 - 50 °C |
| Strømkilde type: | DC |
| Indgangsspænding: | 220-240 V |
| Indgangsfrekvens: | 50/60 Hz |
| Aktuel opladning: | 4 |
