Ctek CT5 Powersport Brugsanvisning
Her er Ctek CT5 Powersport (Batterioplader) brugervejledning. 6 sider på sprog Engelsk med en vægt på 0.2 Mb. Hvis du ikke kan finde svar på dit problem Spørg vores community.
Side 1/6
EN
EN • 3
MANUAL
CONGRATULATIONS
to the purchase of your new professional switch mode battery charger. This charger is
included in a series of professional chargers from CTEK SWEDEN AB and represents the
latest technology in battery charging.
Read safety instruction
HOW TO CHARGE
1. Connect the charger to the battery.
For batteries mounted inside a vehicle
1. Connect the charger according to the
vehicles manual.
2. Connect the charger to the wall socket.
3. Disconnect the charger from the wall socket
before disconnecting the battery.
4. Disconnect the black clamp before the red
clamp.
1 2
2. Connect the charger to the wall socket. The power lamp will indicate that the mains
cable is connected to the wall socket. The power lamp will blink if the battery clamps
are incorrectly connected. The reverse polarity protection will ensure that the battery or
charger will not be damaged.
RECOND LITHIUMNORMAL
NORMAL
BAT T ERY
PROG RA M
ERROR LAMP
RECOND
OPT ION
FULLY CHARGED
LITHIUM
BAT T ERY
PROG RA M
POWER LAMP
MODE BUT T ON
3. Press the MODE-button to select charging program.
NORMAL BATTERY PROGRAM LITHIUM BATTERY PROGRAM
Continue to press the MODE-button to combine charging program with charging options.
RECOND OPTION
Press the MODE-button several times until the desired combination of charging program
and options are lit.
4. Follow the display through the charging process.
The battery is fully charged when the CARE lamp is lit.
5. Stop charging at any time by disconnecting the mains cable from the wall socket.
Problemløsning Ctek CT5 Powersport
Hvis du har læst manualen omhyggeligt, men ikke fundet en løsning på dit problem, bed andre brugere om hjælp
Specifikationer
| Kode for international beskyttelse (IP): | IP65 |
| Vekselstrømsindgangsspænding: | 220 - 240 V |
| Vekselstrømsindgangsfrekvens: | 50 - 60 Hz |
| Produktfarve: | Sort |
| Indbygget skærm: | Ingen |
| LED-indikatorer: | Opladning |
| Udgangsstrøm: | 2.3 A |
| Ladespænding: | 12 V |
| Batterikapacitet (min.): | 5 At |
| Batterikapacitet (maks.): | 25 At |
