Premium Locking Floor Stand Kiosk w/
Digital Password Combination Security Enclosure
PAD-PARAFDC
INSTRUCTION - MANUAL
CONTENTS:
INSTALLATION:
1. Assembling floorstand base :
A
J
x1
M5 Allen Key
3. Attaching enclosure to VESA plate :
1A. Allign the holes on the sntad (A) with holes on the base (B) and turn
in screws (F) with provided allen tool (K) until securely tightened. Shown
above.
2B. When the cable reaches the
bottom of the stand, pull through
the hole at the stand back and
remove the weighted pendant
as shown.
2A. To route a charge cable
through the stand, attach the
weighted pendant to your
charge cable, then pass through
the cutout at the top of the
stand.
3A. Align enclosure (C) VESA holes to VESA plate holes in stand (A) and
from the front of enclosure turn in screws (D) into the threaded VESA
holes with provided allen tool (J) until securely thigtened. Shown above.
C
x1
E
x4
M5 NutM5 x 10
D
x4
M5 x 10
x4
B
x1
x1
K
x1
M6 Allen Key
x1
I
M6 p1-x4
F
x4
M6
2. Cable routing :
C
A
J
A
B
F
K
D
G
I
4. Setting up the foam adapters :
4A. Identify the double sided adhesives (G). Peel away the backing on
both sides. Adhesive four of them behind the foam pieces (I) as
illustrated. They are to adhese the foam to the enclosure. Peel away
the back on the next four and place them on top of the foam pieces as
illustrated. These are to attach the foam to the tablets and ensure
security.
x1
H
x1
G
888-733-4448
Problemløsning CTA Digital PAD-PARAFDC
Hvis du har læst manualen omhyggeligt, men ikke fundet en løsning på dit problem, bed andre brugere om hjælp
Specifikationer
| Bredde: | 307.34 mm |
| Dybde: | 259.08 mm |
| Højde: | 50.8 mm |
| Vægt: | 15512 g |
| Produktfarve: | Sort |
| Materiale: | Stål |
| Stativ bredde: | 406.4 mm |
| Stativ dybde: | 342.9 mm |
| Kabellængde: | 0.45 m |
| Monteringstype: | Gulv |
| Kapabilitet: | iPad Pro 11(2018), iPad Pro 11(2020), iPad Pro 11(2021), iPad Air 10.9 4th (2020), iPad Air 10.9 5th (2022), iPad 10th Gen, Lenovo Tab K10, Samsung Tab S6 Lite, iPad Gen 7, iPad Gen 8(2020), iPad Gen 9(2021), iPad Pro 10.5, iPad Air Gen 3, Galaxy Tab S8, Galaxy Tab S7, Galaxy Tab A 10.1" (2019), Galaxy Tab A8, Lenovo Tab 4, Surface Go, 2, 3, 4, Galaxy Tab S5E, Galaxy Tab S6 and Galaxy Tab A7. |
| Mærke kompatibilitet: | Apple |
| Låsetype: | Nøgle |
| Forbedret kabelstyring: | Ja |
| Maksimal skærmstørrelse kompatibilitet: | 11 " |
| Minimal skærmstørrelse kompatibilitet: | 9.7 " |
| Stativ højde: | 1270 mm |
