R I R A TAD O EPL CEMEN
S RE T TIONWC EN
+
R
INTERFACING SOLUTIONS
A 91311
.cruxinterfacing.com
SWRSB-58
Radio Replacement with Steering Wheel Retention
for select Saab Vehicles
1 of 3
PRODUCT FEATURES:
PARTS INCLUDED:
INSTALLATION DIAGRAM:
AFTERMARKET
RADIO
illumination (+) Orange
Reverse Gear Red/White
Vehicle Speed Sense Purple/White
+12V Constant Yellow
+12V ACC Red
Ground Black
Amp Turn on Blue
Right Front (+) Gray
Right Front (-) Gray/Black
Left Front (+) White
Left Front (-) White/Black
Right Rear (+) Violet
Right Rear (-) Violet/Black
Left Rear (+) Green
Left Rear (-) Green/Black
TO FACTORY
HARNESS
12-Pin Black
Connector
1 2 3
ON
4-Pin
Connector
3.5MM SWC CABLES (Option A or B)
Use the proper 3.5MM to 4-Pin cable for your radio.
Plug in the selected 3.5MM SWC cable to the 4-pin port
on the module. See “DIP SWITCH SETTINGS” section.
NOTE:
rev.072925
TROUBLESHOOTING
LED
LIGHT
LED MODULE FEEDBACK
Solid blue
Flashing blue
Solid red
Red off
CAN recognized
CAN not recognized
Module providing 12V ACC
12V ACC OFF
BLACK / YELLOW FOR PARKING BRAKE OUTPUT
BLACK / YELLOW FOR PARKING BRAKE OUTPUT
Cap or insulate if
not being used
TO
AFTERMARKET
RADIO
Option A:
BLUE / YELLOW
Option B:
To aftermarket
radio SWC wire
or 3.5mm port
Insulate with tape
if not being used
