INSTALLATION INSTRUCTIONS
INSTALLATION INSTRUCTIONS
AxxessInterfaces.com © COPYRIGHT 2025 METRA ELECTRONICS CORPORATION REV. 6/12/25 INSTAXCSD-6V
AxxessInterfaces.com © COPYRIGHT 2025 METRA ELECTRONICS CORPORATION REV. 6/12/25 INSTAXCSD-6V
Product Info
Product Info
INTERFACE FEATURES
INTERFACE COMPONENTS
TOOLS & INSTALLATION ACCESSORIES REQUIRED
• Crimping tool and connectors, or solder gun, solder, and heat shrink
• Tape • Wire cutter • Zip ties
12-volt to 6-volt
Step-Down Converter
• Converts 12-volts DC to 6-volts DC to provide proper voltage for a 6-volt factory backup camera
• AXCSD-6V converter with wiring harness
AXCSD-6V
Connections
Black - Chassis ground
Blue/White - Reverse trigger*
Blue/Red - Camera power
*
Accessory power can also be used if the radio
has the option to monitor the camera while in
motion
INTERFACE FEATURES
INTERFACE COMPONENTS
TOOLS & INSTALLATION ACCESSORIES REQUIRED
• Crimping tool and connectors, or solder gun, solder, and heat shrink
• Tape • Wire cutter • Zip ties
12-volt to 6-volt
Step-Down Converter
• Converts 12-volts DC to 6-volts DC to provide proper voltage for a 6-volt factory backup camera
• AXCSD-6V converter with wiring harness
AXCSD-6V
Connections
Black - Chassis ground
Blue/White - Reverse trigger*
Blue/Red - Camera power
*
Accessory power can also be used if the radio
has the option to monitor the camera while in
motion
