AXDSPX-A2B2

INSTALLATION INSTRUCTIONS

INTERFACE COMPONENTS

Ford Select Models 2018-Up* A2B Data Interface

with Amplifier Bypass Harness & DSP

• AXDSPX-A2B2 interface

• AXDSPX-A2B2 harness

• Amplifier bypass harness

• Radio T-Harness

• AXBK-1

• A2B-EXT

• Bass Knob

• Extension Cable

For Dash Disassembly Instructions, refer to metraonline.com. Enter the year, make, and model of the vehicle in the Vehicle Fit Guide for Radio Install kits.

*Visit axxessinterfaces.com for current application list.

TABLE OF CONTENTS

Interface Features ..................................................2

Things To Know About The AXDSP ...................3-4

Connections ........................................................5-6

Quick Setup Steps: AXDSP-XL App .......................7

LED Feedback .........................................................8

TOOLS REQUIRED

• Crimping tool and connectors, or solder gun, solder, and heat shrink

• Tape

• Wire cutter

• Zip-ties
