TOA Electronics, Inc.
NOISE MASKING MODULE
NM-01
■DESCRIPTION
The NM-01 is a noise masking module to be used in conjunction with TOA’s 9000M2, 900, 700 and BG-2000
series amplifiers. This module generates a noise source to be used for sound masking and audio privacy
applications. Such applications include open-plan office environments or smaller spaces where distracting or
private conversations need to be made unintelligible. The module allows connection of optional external
signal processing equipment (e.g. an equalizer), as required. A simple contact allows for muting of this noise
source, if desired.
■SPECIFICATIONS
Power Source
24 V DC (Supplied from amplifier)
Current Consumption
10mA
Output Level (to amplifier)
300mV
Noise Type
Analog random pink noise
Mute Function
Dry contact, normally open (close to mute)
Input
10kΩ, RCA pin jack
Output
150mV, 600>, RCA pin jack
Dimensions
35(W) x 78(H) x 88(D)mm (1.38” x 3.07” x 3.46”)
Weight
64g (0.14lb)
■APPEARANCE
Front
View
Side View
