INSTRUCTION MANUAL
MONITOR PANEL MP-032B
GENERAL DESCRIPTION
The MP-032B is
designed
to provide aural and visual monitoring for the outputs of up to 10 power
amplifiers. It includes a 5" monitor speaker, a volume control, a watt meter, and a 11-position (OFF and 10
channels) selector switch. The unit also furnished with a line voltage selector on the rear panel to allow
monitoring of 25, 50, 70, and 100-volt line outputs.
FEATURES
1. Monitoring up to 10 channels.
2. Aural and visual monitoring.
3. Monitors 25, 50, 70, and 100-volt lines.
4. Compact, space-saving construction.
SPECIFICATIONS
Functions
Controls
Speaker
Input line voltage
Terminals
Dimensions in mm (in.)
Weight
Finish
Visual / aural monitoring (up to 10 power amplifiers)
Channel selector switch x 1
Monitor volume control x 1
Watt meter x 1
Line voltage selector switch x 1
Full-range 5" speaker
Screw terminals
133 (5.2) H x 483 (19.0) W x 62 (2.4) D
2.2kg (4.85 Ib.)
Black
TOA Corporation
Printed in Japan
133-05-272-30
