Quick-Start Guide
To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.
Manual Revision: May 20, 2021 8:36 PM
To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.
Mini USB port
HDMI
port
Product ID (USB2HDCAPM)
Product Diagram
Front View
Back View
Product Information & Requirements
For the latest drivers, software, manuals, product information, technical specications,
and declarations of conformance, please visit:
www.StarTech.com/USB2HDCAPM
• HDMI video source with cabling x 1
• HDMI display with cabling (optional for video passthrough) x 1
USB 2.0 HD Video Capture Device - 1080p 60fps
Package Contents
• USB 2.0 HDMI video capture device
• USB Cable x 1
• Quick-Start Guide x 1
Installation
Driver Installation
Navigate to and select the tab www.StarTech.com/USB2HDCAPM Drivers/Downloads
to locate and download the latest .Driver
Software Installation
Navigate to and select the www.StarTech.com/USB2HDCAPM Drivers/Downloads
tab to locate and download the latest and the Windows Video Capture Software
accompanying .Software User Guide
Hardware Installation
1. Using the included USB cable, connect the Mini USB port on the capture device to a
USB port on your computer system.
2. Using an HDMI cable (not included), connect the HDMI port on the capture device to
the HDMI output port on your video source device.
*Product may vary from images
*Product may vary from images
Problemløsning StarTech.com USB2HDCAPM
Hvis du har læst manualen omhyggeligt, men ikke fundet en løsning på dit problem, bed andre brugere om hjælp
Specifikationer
| Vægt: | - g |
| Brugervejledning: | Ja |
| Pakkevægt: | 145 g |
| Pakkedybde: | 148 mm |
| Pakkebredde: | 208 mm |
| Pakkehøjde: | 41 mm |
| Understøttede videotilstande: | 720p, 1080p |
| Format til analogt signal: | NTSC, PAL, PAL 60, PAL M |
| Antal HDMI-porte: | 1 |
| Strømforsyningstype: | USB |
| Kabler inkluderet: | USB |
| Understøttede billedformater: | 4:3, 16:9 |
| Certificering: | CE, FCC |
| Pakkens dimensioner (BxDxH): | 145 x 206 x 40 mm |
| Video komprimeringsformater: | H.264, MPEG4 |
| Bæredygtighedscertifikater: | RoHS |
| Værtsgrænseflade: | USB 2.0 |
| Intern: | Ingen |
| Videooptagelse hastighed (PAL): | 30 fps |
| Videooptagelse hastighed (NTSC): | 30 fps |
| Understøttelse af lyd: | Ja |
