Installation
Remove the fiber cover and unhook the 1.
retention bar from the SFP module.
Insert the SFP module into the SFP 2.
receptacle on your networking device.
Secure the SFP module in place by locking 3.
in the retention bar.
Insert the fiber cable into the fiber 4.
connector.
To remove the SFP module, unhook the 5.
retention bar and pull out the module.
Warranty Information
This product is backed by a one year warranty.
In addition, StarTech.com warrants its products against defects in materials
and workmanship for the periods noted, following the initial date of purchase. During this period, the products may be returned for repair, or replacement with
equivalent products at our discretion. The warranty covers parts and labor costs only. StarTech.com does not warrant its products from defects or damages arising
from misuse, abuse, alteration, or normal wear and tear.
Limitation of Liability
In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their officers, directors, employees or agents) for any damages (whether direct
or indirect, special, punitive, incidental, consequential, or otherwise), loss of profits, loss of business, or any pecuniary loss, arising out of or related to the use of
the product exceed the actual price paid for the product. Some states do not allow the exclusion or limitation of incidental or consequential damages. If such laws
apply, the limitations or exclusions contained in this statement may not apply to you.
SFPLHSM
Gigabit 1310nm Single-Mode SFP Fiber
Optical Transceiver - LC (40km)
Installation Guide
Packaging Contents
1 x SFPLHSM transceiver module•
1 x Installation Guide•
Specications
Interface
Small Form-factor
Pluggable MSA
Transmission Standard
1.25Gbps IEEE802.3z
1000BASE-LH
Fiber Connector
Duplex LC
Fiber Type
Single-Mode
Maximum Distance
40km (9/125um)
Hot Pluggable
Yes
Warranty
1 Year
Problemløsning StarTech.com SFPLHSM
Hvis du har læst manualen omhyggeligt, men ikke fundet en løsning på dit problem, bed andre brugere om hjælp
Specifikationer
| Pakkedybde: | 115 mm |
| Pakkebredde: | 25 mm |
| Pakkehøjde: | 65 mm |
| Opbevaringstemperatur (T-T): | -40 - 85 °C |
| Relativ luftfugtighed ved drift (H-H): | 5 - 95 % |
| Driftstemperatur (T-T): | 0 - 70 °C |
| Dimensioner (BxDxH): | 13 x 55 x 9 mm |
| Forbindelsesteknologi: | Ledningsført |
| Kabelteknologi: | 1000BASE-LH |
| Grænseflade: | LC |
| Maksimal overførselsafstand: | 40000 m |
| Bølgelængde: | 1310 nm |
| Fuld duplex: | Ja |
| Overholdelse af branchestandarder: | IEEE 802.3z |
