StarTech.com LTLOCKNBL Brugsanvisning
Her er StarTech.com LTLOCKNBL (slot) brugervejledning. 2 sider på sprog med en vægt på 420,556.0 Mb. Hvis du ikke kan finde svar på dit problem Spørg vores community.
Side 1/2
Quick-Start Guide
To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.
Product Diagram (LTLOCKNBL)
Components Function
1 Locking Hook • Used to connect the Lock to a Lock Slot.
2 Bumper Spacers
• Prevents the Lock from scratching the
connected Device.
3 Security Cable
• Used to secure a Device to a secure stationary
object.
4 Release Button • Used to release the Lock from the Lock Slot.
5 Guide Line
• Used to enter a combination on the Dials.
• Align the combination digits with the Guide
Line.
6 Reset Screw
• Used to set a new combination.
Note: Once the combination is changed, if you
lose the new combination you will not be able to
reset the combination.
7 Dials • Used to enter the Lock’s combination.
4-Digit Combination Laptop Lock - for Wedge Security Slot
1
Requirements
For the latest requirements, please visit www.startech.com/LTLOCKNBL.
• Default Combination = 0-0-0-0
Setting a New Combination
1. Align the numbers on the Dial with the Guide Line using the default combination
0-0-0-0.
2. Insert a Flathead Screwdriver (sold separately) into the Reset Screw and push the
Reset Screw in toward the Lock.
3. With the Reset Screw pushed in, turn the Reset Screw clockwise 90 degrees.
4. Rotate each of the Dials to the desired number.
5. Insert the Flathead Screwdriver into the Reset Screw and turn the Reset Screw
counter-clockwise 90 degrees, moving the Reset Screw back to its original position.
The Reset Screw will pop back out when it is in the original position.
Note: Be sure to write down the new combination and keep it in a secure location
away from the lock.
6. To set a new combination follow steps 1 - 5 using the new combination set up in
Step 4 instead of the default combination.
Locking a Device
1. Wrap the Security Cable around a secure stationary object and pull the Lock
through the loop on the Security Cable.
Security Cable
2. Press and hold the Release Button and insert the Locking Hooks into the Lock Slot
on a Laptop, Docking Station, or any other compatible Device.
2
3
4
6
5
7
Problemløsning StarTech.com LTLOCKNBL
Hvis du har læst manualen omhyggeligt, men ikke fundet en løsning på dit problem, bed andre brugere om hjælp
Specifikationer
| Bredde: | 54 mm |
| Højde: | 18 mm |
| Vægt: | 138 g |
| Antal pr. pakke: | 1 stk |
| Brugervejledning: | Ja |
| Produktfarve: | Sort, sølv |
| Pakkevægt: | 150 g |
| Pakkedybde: | 220 mm |
| Pakkebredde: | 130 mm |
| Pakkehøjde: | - mm |
| Materiale: | Zink stål |
| Kabellængde: | 2.043 m |
| Harmoniseret systemkode (HS): | 83014090 |
| Bæredygtighedscertifikater: | RoHS |
| Hovedkassen højde (udvendigt): | 230 mm |
| Hovedkassens længde (udvendigt): | 325 mm |
| Hovedkassens bredde (udvendigt): | 290 mm |
| Kabellåseslids type: | Noble |
| Produkter pr. hovedkasse (udvendigt): | 40 stk |
| Låsetype: | Kombinationslås |
| Bedste anvendelsesmuligheder: | Laptop |
| Funktioner: | 1 |
| Antal kombinationer: | 10000 |
