StarTech.com
Audio/video konverter
HD2DPVGADVI
StarTech.com HD2DPVGADVI Brugsanvisning
Her er StarTech.com HD2DPVGADVI (Audio/video konverter) brugervejledning. 2 sider på sprog med en vægt på 299,544.0 Mb. Hvis du ikke kan finde svar på dit problem Spørg vores community.
Side 1/2
Quick start guide
DE: Bedienungsanleitung - de.startech.com
FR: Guide de l'utilisateur - fr.startech.com
ES: Guía del usuario - es.startech.com
IT: Guida per l'uso - it.startech.com
NL: Gebruiksaanwijzing - nl.startech.com
PT: Guia do usuário - pt.startech.com
Manual Revision: 12/30/2016
For the latest information, technical specications, and support for
this product, please visit www.startech.com/HD2DPVGADVI
Packaging contents
• 1 x travel A/V adapter
• 1 x quick start guide
System requirements
• HDMI enabled video source device, such as a computer
• DisplayPort, VGA or DVI display with cabling
HD2DPVGADVI
Travel A/V Adapter: 3-in-1 HDMI® to DisplayPort™, VGA or DVI
*actual product may vary from photos
Product overview
Front view
1. USB power cable
2. HDMI input cable
3. DisplayPort output port
Rear view
About this product
While you’re traveling, you never know what type of display monitor
or projector you’ll need to connect your laptop to. This travel adapter
lets you connect your HDMI enabled source device, such as your
Ultrabook™ or laptop computer, to any DisplayPort, DVI or VGA
display.
Important operation notes
• To ensure optimal performance, connect the USB power cable to a
USB power source, while the adapter is in operation.
• If you’re connecting to a DisplayPort or DVI display, the VGA
output button should not be pushed in.
• If you’re connecting to a VGA display, the VGA output button
should be pushed in.
• This adapter will not output digitally encrypted content through
the VGA port.
• Only one video output is supported on the video adapter at a
time. If multiple connections are made, only one of the video
outputs will function.
Technical specications
4. DVI output port
5. VGA output port
1. VGA output button
Video output Maximum resolution Audio support
DisplayPort
3840×2160
@ 30Hz
(4K)
2-channel
(stereo)
VGA
1920x1200
@ 60Hz
(HD)
Not applicable
DVI
1920x1200
@ 60Hz
(Dual-link)
Not applicable
Problemløsning StarTech.com HD2DPVGADVI
Hvis du har læst manualen omhyggeligt, men ikke fundet en løsning på dit problem, bed andre brugere om hjælp
Specifikationer
| Bredde: | 55 mm |
| Dybde: | 300 mm |
| Højde: | 15 mm |
| Vægt: | 76 g |
| Produktfarve: | Sort |
| Pakkevægt: | 138 g |
| Pakkedybde: | 170 mm |
| Pakkebredde: | 144 mm |
| Pakkehøjde: | 30 mm |
| Opbevaringstemperatur (T-T): | -10 - 55 °C |
| Relativ luftfugtighed ved drift (H-H): | 40 - 50 % |
| Driftstemperatur (T-T): | 0 - 70 °C |
| Hurtig installationsvejledning: | Ja |
| Lyd-output kanaler: | 2.0 kanaler |
| Certificering: | CE, FCC, RoHS |
| Harmoniseret systemkode (HS): | 84733080 |
| Maksimal videoopløsning: | 3840 x 2160 pixel |
| Værtsgrænseflade: | HDMI |
| Plug and play: | Ja |
| USB-drevet: | Ja |
| Output-grænseflade: | DisplayPort/DVI-I/VGA |
| Understøttede opløsninger: | DisplayPort: 3840 x 2160, 2560 x 1600, 1920 x 1200, 1920 x 1080, 1280 x 720\nVGA: 1920 x 1200, 1920 x 1080, 1280 x 720\nDVI: 2560x1600, 1920 x 1200, 1920 x 1080, 1280 x 720 |
| Understøttelse af lyd: | Ja |
