Quick-Start Guide
Product ID
H2MPV-MONITOR-MOUNT
Dual Monitor Desk Mount - Single Heavy-Duty Pole - Up to 49” 32:9 Monitors
Feature Function
1VESA Plate
• Use to mount a onto the Monitor Monitor Mount
• Features a design for mounting and Quick-Release
unmounting of the Monitor
2Monitor Mount • Secures the along the Monitor Pole
3Pole Cap • Enables to pass-through into the Cables Pole
• Composed of two halves that are press tted onto the Pole
4Support Collar
• Supports the weight of the while adjusting the Monitor
Monitor Mount Pole around the
• secure it into place Set Screws
Note: The Support Collar is not meant to solely support the
Monitor weight
5Monitor Mount Lever • Use to tighten or loosen the Monitor Mount
6Cable Pass-Through Hole • Route cables through the for Pole Cable Management
7Pole Assembly
• Enables to vary the height of the Monitors
• A single assembly composed of the and Pole Desk Clamp,
Upper
8Desk Clamp, Lower
• Secures the to a desk or tableMonitor Desk Mount
• Adjustable height to match the thickness of the desk or table
• Supported thickness range of 1to 3.9-inch (25 to 100mm)
Package Contents
• Desk Clamp, Lower ( ) x 1A
• Pole Assembly ( ) x 1B
• Pole Cap ( ) x 1C
• Monitor Mount ( ) x 2D
• VESA Plate ( ) x 2E
• Support Collar ( ) x 2F
• M4x10mm Screws ( )x 8G
• M4x16mm Screws( ) x 8H
• 3/8” x 1/2” Screws ( ) x 2I
• Spacers ( ) x 8J
• M6 Hex Key ( ) x 1K
• M3 Hex Key ( ) x 1L
• Wrench ( ) x 1M
*Product may vary from image
1
8
3
5
2
6
2
6
7
1
4
5
4
