Quick-Start Guide
To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.
Manual Revision: August 10, 2021
Product Diagram (DK31C3HDPD and DK31C3HDPDUE)
Front View
Rear View
Side View
Port Function
1 USB-C Charge Port
• Connect a USB-C Peripheral or charge a Mobile
Device
• USB 3.1 Gen 1
• Transmits power and/or data
• Supports BC1.2 9V/2A (18W) charging
2 USB-A Charge Port
• Connect a USB-A Peripheral or charge a Mobile
Device
• USB 3.1 Gen 1
• Transmits power and/or data
• Supports BC1.2 5V/1.5A (7.5W) charging
3
Audio Input/Output
Port
• Connect a Headset or Speakers for audio
input/output
• 3.5 mm 4-position headset audio jack
USB-C™ 10Gbps & USB-A Triple 4K Monitor Hybrid Dock - DP and/or HDMI - 85W PD
4 Power Button
• Power the Docking Station on and o
• Integrated LED Indicator is illuminated white when
the Docking Station is powered on
5 DC Power Input Port
• Connect the Universal Power Adapter to supply
power to the Docking Station
• Type-M barrel connector
• 20V 7.5A
6 USB-C Host Port
• Connect to a USB-A or USB-C Port on a Host Laptop
using the USB-C Cable (with Attached USB-C to
USB-A Adapter)
• USB 3.1 Gen 2
• Power Delivery 3.0 Specication
• Charge Host USB-C Laptop with up to 85W
• (Optional) Connect a Screw Locking USB-C Cable
(sold separately)
7
Video 1 DisplayPort
Port
--Or--
Video 1 HDMI Port
• Connect a DisplayPort Enabled Display Device
--Or--
• Connect an HDMI Enabled Display Device
8
Video 2 DisplayPort
Port
--Or--
Video 2 HDMI Port
• Connect a DisplayPort Enabled Display Device
--Or--
• Connect an HDMI Enabled Display Device
9
Video 3 DisplayPort
Port
--Or--
Video 3 HDMI Port
• Connect a DisplayPort Enabled Display Device
--Or--
• Connect an HDMI Enabled Display Device
10 RJ45 Port
• Connect a CAT5e/6 Cable to a Network Device to
establish a network connection
11
10G USB-C Peripheral
Port
--And--
10G USB-A Peripheral
Port
• Connect a USB-C and/or USB-A Peripheral
• USB 3.1 Gen 2
• Bandwidth is shared between the two Ports
12
5G USB-A Peripheral
Ports
• Connect up to two USB-A Peripherals
• USB 3.1 Gen 1
• Bandwidth is shared between the two Ports
13 Mounting Holes
• Mount the Docking Station to the underside of a
Desk or to a Wall
14 Lock Slot
• Connect a K-Slot Style Locking Device
• Deter the theft of your Docking Station
21
3 4
5 6 7 8 9
10
11
12
14
13
13
Problemløsning StarTech.com DK31C3HDPD
Hvis du har læst manualen omhyggeligt, men ikke fundet en løsning på dit problem, bed andre brugere om hjælp
Specifikationer
| Vekselstrømsindgangsspænding: | 100 - 240 V |
| Bredde: | 84 mm |
| Dybde: | 233 mm |
| Højde: | 37 mm |
| Vægt: | 365 g |
| Brugervejledning: | Ja |
| Produktfarve: | Black, Grey |
| Pakkevægt: | 1700 g |
| Pakkedybde: | 253 mm |
| Pakkebredde: | 172 mm |
| Pakkehøjde: | 91 mm |
| HD-type: | 4K Ultra HD |
| Opbevaringstemperatur (T-T): | -20 - 70 °C |
| Relativ luftfugtighed ved drift (H-H): | 0 - 95 % |
| Antal HDMI-porte: | 3 |
| Ethernet LAN-porte (RJ-45): | 1 |
| Antal USB 3.2 Gen 1 (3.1 Gen 1) type-A-porte: | 3 |
| Udgange til hovedtelefoner: | 1 |
| Ethernet LAN: | Ja |
| Driftstemperatur (T-T): | 0 - 50 °C |
| Ethernet LAN-datahastigheder: | 10,100,1000 Mbit/s |
| Husmateriale: | Aluminium, Duralumin |
| Kabler inkluderet: | USB Type-C til USB Type-C |
| Forbindelsesteknologi: | Ledningsført |
| DC-in-stik: | Ja |
| Strømkilde type: | Vekselstrøm |
| Udgangsspænding: | 20 V |
| Udgangsstrøm: | 7.5 A |
| AC-adapter inkluderet: | Ja |
| Kabellængde: | 1 m |
| Indbygget kortlæser: | Ingen |
| Bæredygtighedscertifikater: | RoHS |
| Mikrofonindgang: | Ja |
| Slot til kabellås: | Ja |
| Understøttede Windows-operativsystemer: | Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 IoT Enterprise, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64 |
| Understøttede Mac-operativsystemer: | Mac OS X 10.6 Snow Leopard, Mac OS X 13.0 Ventura |
| Hovedkassen højde (udvendigt): | 300 mm |
| Hovedkassens længde (udvendigt): | 395 mm |
| Hovedkassens bredde (udvendigt): | 315 mm |
| Værtsgrænseflade: | USB 3.2 Gen 2 (3.1 Gen 2) Type-C |
| Indgangsstrøm: | 2.5 A |
| Antal DisplayPorts: | 3 |
| Kabellåseslids type: | Kensington |
| Produkter pr. hovedkasse (udvendigt): | 6 stk |
| Fuld duplex: | Ja |
| Antal USB 3.2 Gen 1 (3.1 Gen 1) type-C-porte: | 1 |
| Kombineret hovedtelefon/mikrofon-port: | Ja |
| Strømstiktype: | Type M |
| Maksimal digital opløsning: | 3840 x 2160 pixel |
| Dataoverførselshastighed: | 10 Gbit/sek. |
| USB strømforsyning: | Ja |
| Kompatible strømplug typer: | AU, JP, US |
| Grænseflade-adaptere inkluderet: | USB Type-A male - USB Type-C female |
| Antal USB 3.2 Gen 2 (3.1 Gen 2) type-C-porte: | 1 |
| Antal USB 3.2 Gen 2 (3.1 Gen 2) type-A-porte: | 1 |
| USB strømforsyning op til: | 85 W |
| Understøtter UASP: | Ja |
| Chipsæt: | Realtek RTS5423, Realtek RTS5411, Realtek RTS5412, Realtek RTS5451, Realtek RTD2142, DisplayLink DL6950 |
