Quick-Start Guide
To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.
Manual Revision: August 30, 2019
Product Diagram (CMSCOILED)
Part Function
1
Cable-Management
Sleeve
• Organize Cables into one bundle
2 Cable Insertion Tool • Guides Cables into the Cable-Management Sleeve
Requirements
For the latest requirements please visit: www.startech.com/CMSCOILED.
Installation
Basic
1. Open the Cable Channel by rotating the Tube within the Cable Insertion Tool.
2. Feed the Cables into the Cable Insertion Tool though the V-Shaped Opening in
the Tube. (Figure 1)
Spiral Cable-Management Sleeve - Black
3. Rotate the Tube in the Cable Insertion Tool to close the Cable Channel. (Figure 2)
4. Insert the Nose of the Cable Insertion Tool into one end of the Cable-
Management Sleeve.
1
2
Figure 2
Nose
Figure 1
Cable
Channel
V-Shaped
Opening
Tube
Problemløsning StarTech.com CMSCOILED3
Hvis du har læst manualen omhyggeligt, men ikke fundet en løsning på dit problem, bed andre brugere om hjælp
Specifikationer
| Type: | Kabelmuffe |
| Bredde: | 45 mm |
| Højde: | 45 mm |
| Vægt: | 301 g |
| Antal pr. pakke: | 1 stk |
| Produktfarve: | Sort |
| Pakkevægt: | 345 g |
| Pakkedybde: | 460 mm |
| Pakkebredde: | 340 mm |
| Pakkehøjde: | 40 mm |
| Hurtig start guide: | Ja |
| Materiale: | Polyethylen (PE) |
| Certificering: | CE, REACH |
| Harmoniseret systemkode (HS): | 85389099 |
| Bæredygtighedscertifikater: | RoHS |
| Længde: | 1.5 m |
