Quick-Start Guide
To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.
Manual Revision: June 17, 2021
Product Diagram (8P6G-PCIE-SATA-CARD)
Front View
Port Function
1
Mini-SAS Connector
(SFF-8087)
• Connect to the SATA Stoage Devices PCIe SATA
Card Mini-SAS to 4x SATA Cable using
• SATA Ports 1-4
2
Mini-SAS Connector
(SFF-8087)
• Connect to the SATA Stoage Devices PCIe SATA
Card Mini-SAS to 4x SATA Cable using
• SATA Ports 5-8
3PCIe p1-x4 Connector
• Connect the to the in PCIe SATA Card PCIe Slot
the Computer
Product Information
For the latest product information, technical specications, manuals, and Declarations
of Conformance, please visit:
www.startech.com/8P6G-PCIE-SATA-CARD.
Package Contents
• PCIe SATA Card x 1
• Mini-SAS to 4x SATA Cable x 2
• Full-Prole Bracket (Installed) x 1
• Low-Prole Bracket x 1
• Quick-Start Guide x 1
Requirements
• Computer with an available PCIe slot (x4/8/16)
• Phillips Head Screwdriver
8-Port SATA 6 Gbps PCI Express SATA Controller Card
Hardware Installation
Warning: PCIe Cards can be damaged by static electricity. Make sure that the
Installer Computer Case is properly grounded before they open the or touch the
PCIe SATA Card. The should wear an when installing any Installer Anti-Static Strap
computer component. If an is not available, discharge any built-up Anti-Static Strap
static electricity by touching a large for several seconds. Grounded Metal Surface
Only handle the by its edges and do not touch the gold connectors. PCIe SATA Card
Installing the Low-Prole Bracket
By default the is attached to the . Depending on Full-Prole Bracket PCIe SATA Card
the system conguration it may be necessary to remove the to Full-Prole Bracket
replace with the (included).Low-Prole Bracket
1. Remove the 2x securing the , using a Phillips Head Screws Full-Prole Bracket
Phillips Head Screwdriver.
2. Remove the and replace with the Full-Prole Bracket Low-Prole Bracket
(included).
3. Install the 2x removed in step 1 and tighten, using a Phillips Head Screws Phillips
Head Screwdriver.
Installing the Card
1. Turn o the and any that are connected Computer Peripheral Devices
(e.g. printers, external hard drives, etc.).
2. Unplug the from the rear of the and disconnect any Power Cable Computer
Peripheral Devices that are connected.
3. Remove the from the . Cover Computer Case
Note: Consult the documentation that came with the for details about Computer
how to do this safely.
4. Locate an open (x4/8/16) and remove the corresponding PCIe Slot Metal Cover
Plate Computer Case Metal Cover Plate from the rear of the . In most instances, the
is attached to the rear of the with a single . Computer Case Phillips Head Screw
Save this for the next step. Phillips Head Screw
5. Gently insert the into the open (x4/8/16) and fasten the PCIe SATA Card PCIe Slot
Bracket Computer Case Phillips Head Screw to the rear of the , using the from step
4.
6. Connect the of each to the Mini-SAS Connector Mini-SAS to SATA Cable Mini-SAS
Connectors PCIe SATA Card. of the
7. Connect the of the to a maximum of 8 SATA Connectors Mini-SAS to SATA Cables
SATA Storage Devices.
8. Replace the from the that was removed in step 3.Cover Computer
9. Reconnect all of the that were disconnected in step 2.Peripheral Devices
10. Reconnect the to the rear of the .Power Cable Computer
3
2
1
Problemløsning StarTech.com 8P6G-PCIE-SATA-CARD
Hvis du har læst manualen omhyggeligt, men ikke fundet en løsning på dit problem, bed andre brugere om hjælp
Specifikationer
| Bredde: | 68.6 mm |
| Dybde: | 150 mm |
| Højde: | 14.6 mm |
| Vægt: | 75 g |
| Produktfarve: | Sort |
| Pakkevægt: | 81 g |
| Pakkedybde: | 155 mm |
| Pakkebredde: | 230 mm |
| Pakkehøjde: | 55 mm |
| Opbevaringstemperatur (T-T): | -20 - 60 °C |
| Relativ luftfugtighed ved drift (H-H): | 20 - 80 % |
| Driftstemperatur (T-T): | 5 - 50 °C |
| Hurtig installationsvejledning: | Ja |
| Kabler inkluderet: | SATA |
| Harmoniseret systemkode (HS): | 84733020 |
| Bæredygtighedscertifikater: | RoHS |
| Understøttede Mac-operativsystemer: | Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks, Mac OS X 11.0 Big Sur, Mac OS X 13.0 Ventura |
| Understøttede Linux-operativsystemer: | Ja |
| Hovedkassen højde (udvendigt): | 380 mm |
| Hovedkassens længde (udvendigt): | 510 mm |
| Hovedkassens bredde (udvendigt): | 610 mm |
| Værtsgrænseflade: | PCIe |
| Intern: | Ja |
| Produkter pr. hovedkasse (udvendigt): | 40 stk |
| Understøtter S.M.A.R.T.: | Ja |
| Understøttelse af TRIM: | Ja |
| Understøttede operativsystemer til servere: | Windows Server 2003, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016, Windows Server 2019 |
| Monteringsbeslag inkluderet: | Ja |
| Output-grænseflade: | Mini-SAS |
| Udvidelseskort standard: | PCI 2.0 |
| Dataoverførselshastighed (maks.): | 6 Gbit/sek. |
| Chipsæt: | Pericom - PI7C9X2G608GP, ASMedia - ASM1061 |
| Eksterne mini-SAS-porte: | 2 |
| SATA revision: | 3.0 |
| Port multiplikator: | Ja |
