P16S18G - 16-Port Gigabit PoE + 2-Port Gigabit SFP + 2-Port Gigabit Copper Ethernet Switch
User Manual
Packing List
Open the product box and carefully unpack all contents. The box should contain the following items.
Please check before installation, if any are missing, please contact your distributor immediately.
Items Quantity
Switch 1 pc
AC Power Cable 1 pc
Mounting Accessories 1 set
Quick Installation Guide 1 pc
Product Introduction
This switch provides sixteen Gigabit Ethernet RJ-45 downlink ports, two Gigabit Ethernet RJ-45 uplink
ports and two Gigabit SFP uplink ports. All RJ-45 downlink ports support Power-over-Ethernet (PoE+)
and deliver up to 30W power per port.
The switches work in three modes: default, VLAN, and flow control. It can be widely used in video
security monitoring systems, network projects, etc.
Hardware Introduction
Dimensions (mm)
────────◀◀◀
16-Port Gigabit PoE + 2-Port Gigabit SFP + 2-Port Gigabit Copper Ethernet Switch
Front Panel (16-Port PoE Switch)
Rear Panel (16-Port PoE Switch)
Led Indicators
Indicators Status Descriptions
Power Power Supply Indicator
On The Main Power Supply is working.
Off The Main Power Supply is off.
Link Port Link Indicator
On The port is linking normally.
Blink The port is transmitting or receiving data.
Off The port links down.
PoE Port PoE Indicator
On The port is supplying PoE normally.
Off The port stopped supplying PoE.
DIP Switch
Status Descriptions
Default
Default mode. All ports are free to communicate
VLAN
Downlink ports are isolated from each other, but can communicate with uplink ports
Flow control
Enables flow control function, this mode is suitable for video surveillance transmission
Note:
After changing the mode, please power on the device again to enter the corresponding mode.
